Factory Ford Fusion Workshop Manual (2013–2017)
This is the official factory-level service manual for the second-generation Ford Fusion, covering all US-market models from 2013 through the pre-facelift 2017 model year — the same documentation used by Ford-authorized dealerships and repair facilities.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.5L EcoBoost, 1.6L EcoBoost, 2.0L EcoBoost, 2.3L Duratec, 2.5L Duratec iVCT; Hybrid 2.0L Atkinson-cycle |
| Diesel | 2.0L Duratorq TDCi |
| Transmissions | 6-speed manual, 6-speed automatic (6F35), 6-speed SelectShift automatic, eCVT (hybrid models) |
| Drive | FWD, AWD |
| Model Years | 2013, 2014, 2015, 2016, 2017 |
| Badge Twins | Ford Mondeo MK5 (international markets) |
Common Fusion Repairs Covered
| System | Procedures |
|---|---|
| 1.5L/1.6L EcoBoost Cooling | Coolant leak diagnosis and repair at the cylinder head coolant port — a known issue on these engines; head gasket inspection and replacement procedures |
| 6F35 Automatic Transmission | Shudder and harsh shift diagnosis, solenoid replacement, fluid and filter service, valve body removal and inspection |
| Door Latch Mechanism | Door latch failure diagnosis and replacement — a documented NHTSA recall item affecting multiple model years; cable and actuator procedures included |
| Suspension & Steering | Front strut and rear shock replacement, wheel bearing hub assembly service, electric power steering rack calibration and replacement |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the Ford Fusion Energi plug-in hybrid covered in this manual?
Yes. The manual includes coverage for both the Fusion Hybrid and Fusion Energi plug-in hybrid variants, encompassing the 2.0L Atkinson-cycle engine, eCVT transmission, and high-voltage battery system procedures applicable to 2013–2017 model years.
Is the Ford Fusion the same vehicle as the Mondeo MK5?
Yes. The second-generation Fusion (2013–2017) shares its CD4 platform with the Ford Mondeo MK5 sold in Europe and other international markets. The two vehicles are mechanically closely related, and much of the factory service content overlaps.
Does the manual include wiring diagrams for the SYNC infotainment and MyFord Touch systems?
Yes. Full electrical schematics are included for the SYNC and MyFord Touch systems alongside engine management, ABS, airbag, climate control, lighting, and all body electrical circuits. Connector pinouts and wire color codes are provided throughout.
What format is the manual?
The manual is delivered as a PDF file, compatible with Windows, Mac, Linux, Android, and iOS devices. After purchase, download is immediate, and you retain lifetime access for re-downloads at no additional charge.
