Factory Alfa Romeo 159 Workshop Manual (2004–2011)
This official Type 939 factory-level repair resource covers every Alfa Romeo 159 Sedan and Sportwagon sold between 2004 and 2011, giving US owners and technicians the same depth of service data used by dealership mechanics worldwide.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.8L MPI (140 hp), 1.9L JTS (160 hp), 2.2L JTS (185 hp), 3.2L V6 JTS Q4 (260 hp) |
| Diesel | 1.9L JTDm (120–150 hp), 2.0L JTDm (170 hp), 2.4L JTDm (200–210 hp) |
| Transmissions | 6-speed manual, Selespeed automated manual, Q-Tronic automatic |
| Drive | RWD; Q4 AWD (3.2L V6 models) |
| Model Years | 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011 |
| Badge Twins | Alfa Romeo Brera / Spider (Type 939 platform shared components) |
Common 159 Repairs Covered
| System | Procedures |
|---|---|
| Selespeed Transmission | Actuator pressure calibration, clutch bite-point reset, hydraulic pump replacement |
| JTDm Diesel Fuel System | High-pressure common-rail injector removal/installation, EGR valve cleaning and replacement |
| Front Suspension | Lower control arm bushing replacement, front wheel bearing hub assembly service |
| Electrical / CAN-Bus | Wiring diagrams, connector pinouts, ABS/ESP module diagnostics, climate control fault tracing |
Format & Delivery
Dealer-style E.Learn interactive software compatible with Windows 11/10/8/7/Vista/XP, Mac, and Linux. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does my Alfa Romeo 159 Selespeed hesitate or lurch during gear changes?
The Selespeed automated manual transmission is prone to hydraulic actuator wear and clutch bite-point drift over time. This manual provides the full calibration procedure, actuator pressure specifications, and hydraulic pump replacement steps needed to restore smooth shifting on 2004–2011 Type 939 models.
Does coverage extend to the Alfa Romeo Brera and Spider?
Because the Brera and Spider share the Type 939 platform with the 159, many chassis, suspension, and powertrain procedures apply directly. The manual explicitly references shared components across these badge siblings.
Are wiring diagrams and CAN-bus schematics included?
Yes. Full electrical schematics cover the engine management system, ABS/ESP, climate control, infotainment, and all body circuits, complete with connector pinout tables for every module in the 159’s CAN-bus network.
What format is the manual?
The manual is delivered as E.Learn interactive software — not a static PDF. It runs on Windows, Mac, and Linux, and features searchable text, zoom-capable diagrams, bookmarks, and multi-language support including English, Italian, German, Spanish, French, Dutch, and Portuguese.
