Factory Cadillac ATS Workshop Manual (2013-2019)
This factory-level service manual gives US technicians and ATS owners complete repair and diagnostic coverage for every model year from 2013 through 2019, spanning the Sedan, Coupe, and high-performance ATS-V variants.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.0L LTG Turbo I4, 2.5L LCV I4, 3.6L LGX V6, 3.6L LF4 Twin-Turbo V6 (ATS-V) |
| Diesel | N/A |
| Transmissions | 6-speed manual, Hydra-Matic 6L45 6-speed automatic, 8L45 8-speed automatic |
| Drive | RWD, AWD |
| Model Years | 2013, 2014, 2015, 2016, 2017, 2018, 2019 |
| Badge Twins | N/A |
Common ATS Repairs Covered
| System | Procedures |
|---|---|
| 2.0L LTG Turbo Oil Consumption | Piston ring inspection, PCV valve replacement, crankcase ventilation diagnosis |
| Magnetic Ride Control | Shock absorber replacement, position sensor calibration, MRC module diagnostics |
| CUE Infotainment System | Touchscreen delamination repair, module replacement, software update procedures |
| Brake System | Brembo caliper service (ATS-V), rotor resurfacing, ABS module diagnostics, pad replacement torque specs |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this manual cover the ATS-V with its twin-turbo V6?
Yes. The 3.6L LF4 twin-turbocharged V6 producing 464 horsepower in ATS-V Sedan and Coupe models is fully documented, including enhanced Brembo brake procedures, Magnetic Ride Control calibration, and the Tremec TR6060 6-speed manual gearbox specific to that variant.
What body styles and trim levels are included?
All ATS body styles are covered: the four-door Sedan and the two-door Coupe. Trim levels range from the base Standard through Luxury, Premium Luxury, and V-Sport, up to the full ATS-V performance editions. All ride on GM’s Alpha platform, sharing procedures across configurations where applicable.
Are wiring diagrams included for the CUE infotainment and electrical systems?
Complete wiring diagrams are included for all ATS electrical systems, covering the CUE infotainment network, engine management, lighting circuits, body control modules, and connector pin assignments. Color-coded schematics with ground point locations and fuse box layouts support efficient electrical fault diagnosis.
What format is the manual?
The manual is delivered as a fully searchable PDF, compatible with Windows, Mac, iOS, and Android devices. After purchase, your download link is available immediately and remains accessible for lifetime re-downloads.
