Factory Cadillac XTS Workshop Manual (2013-2019)
This factory-level repair manual covers the complete second-generation Cadillac XTS full-size luxury sedan sold in the United States from 2013 through 2019, including every trim level from Luxury to the twin-turbocharged V-Sport.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.6L V6 LFX (304 hp, naturally aspirated), 3.6L V6 LF3 (410 hp, twin-turbocharged – V-Sport) |
| Diesel | N/A |
| Transmissions | 6-speed automatic 6T70 / 6T75; 6T70 MHD (AWD variants) |
| Drive | FWD, AWD |
| Model Years | 2013, 2014, 2015, 2016, 2017, 2018, 2019 |
| Badge Twins | N/A |
Common XTS Repairs Covered
| System | Procedures |
|---|---|
| CUE Infotainment | Touchscreen unresponsiveness diagnosis, module replacement, software reset procedures |
| Magnetic Ride Control Suspension | Shock absorber replacement, damper calibration, ride height sensor diagnosis |
| 3.6L LFX Timing Chain | Timing chain stretch inspection, tensioner replacement, camshaft position sensor service |
| 6T70 Transmission | Harsh shifting diagnosis, fluid and filter service, valve body inspection and repair |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the twin-turbocharged V-Sport powertrain fully covered?
Yes. The manual includes complete service procedures for the 3.6L LF3 twin-turbocharged engine found in V-Sport models, covering turbocharger inspection, intercooler service, boost system diagnostics, and all associated wiring – in addition to the standard LFX naturally aspirated engine.
Does the manual cover both FWD and AWD configurations?
Yes. Both front-wheel-drive and all-wheel-drive XTS variants are addressed, including the AWD-specific 6T70 MHD transmission, front differential, and rear drive module service procedures.
Are the Magnetic Ride Control and CUE infotainment systems documented?
Yes. Detailed wiring diagrams, sensor locations, calibration steps, and component replacement instructions are included for both the Magnetic Ride Control suspension system and the CUE touchscreen infotainment unit – two of the most frequently serviced systems on the XTS.
What format is the manual?
The manual is a PDF file, downloadable immediately after purchase. It is fully searchable, zoomable, and compatible with Windows, Mac, iOS, Android, and any device running a standard PDF reader. Pages can be printed as needed for bench reference.
