Description
Factory Chevrolet Kalos Workshop Manual (2004–2011)
This factory-level service manual delivers complete repair and maintenance coverage for the Chevrolet Kalos sold in US and global markets from 2004 through 2011, covering all body styles and every powertrain combination offered during the full production run.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.2L S-TEC SOHC inline-4 (72 hp), 1.4L E-TEC SOHC inline-4 (83 hp), 1.4L DOHC 16-valve inline-4 (94 hp) |
| Diesel | N/A |
| Transmissions | 5-speed manual, 4-speed automatic |
| Drive | FWD |
| Model Years | 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011 |
| Badge Twins | Daewoo Kalos, Holden Barina (T200 platform) |
Common Kalos Repairs Covered
| System | Procedures |
|---|---|
| Timing Chain (1.4L DOHC) | Chain tensioner inspection, replacement, and timing mark alignment procedures |
| Cooling System | Thermostat replacement, coolant flush, radiator removal, and water pump service |
| Front Suspension | Strut replacement, lower control arm bushing service, and wheel bearing replacement |
| Electrical / Central Locking | Door lock actuator diagnosis, wiring harness inspection, and BCM fault tracing using full wiring diagrams |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the 1.4L DOHC engine have known timing chain issues?
Yes. The 1.4L 16-valve DOHC engine in the Kalos is known for timing chain tensioner wear, particularly on higher-mileage examples. This manual includes complete tensioner inspection criteria, chain slack measurement procedures, and step-by-step replacement instructions with torque specifications to address this issue properly.
Does this manual cover the Daewoo Kalos and Holden Barina as well?
Yes. The Chevrolet Kalos shares the GM T200 platform with the Daewoo Kalos and the Australian-market Holden Barina. Because the mechanical architecture and electrical systems are identical across these badge twins, this manual applies directly to all three variants across the 2004–2011 production span.
Are all body styles included — hatchback and sedan?
Yes. The manual covers the three-door hatchback, five-door hatchback, and four-door sedan body styles. Body-specific procedures such as door panel removal, trim fitting, and chassis dimensions are documented for each variant, including left- and right-hand-drive configurations.
What format is the manual?
The manual is delivered as a PDF file, compatible with Windows, Mac, iOS, and Android devices using any standard PDF reader. The document is fully searchable by keyword, and individual pages or entire sections can be printed for workshop use.
