Factory Chrysler Pacifica Workshop Manual (2017–2020)
This factory-sourced service manual gives US Pacifica owners and independent technicians complete repair and diagnostic coverage for every 2017–2020 model year, from base L trim through the top-tier Pinnacle edition — including the plug-in hybrid variant.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.6L Pentastar V6 (287 hp) |
| Hybrid | 3.6L V6 + dual electric motors, 16 kWh lithium-ion battery (Pacifica Hybrid) |
| Transmissions | 9-speed 948TE automatic; eFlite electrically variable transmission (hybrid) |
| Drive | FWD |
| Model Years | 2017, 2018, 2019, 2020 |
| Badge Twins | N/A |
Common Pacifica Repairs Covered
| System | Procedures |
|---|---|
| 9-Speed 948TE Transmission | Harsh shifting / shudder diagnosis, fluid flush, valve body service, TCM reprogramming |
| Power Sliding Doors | Actuator and latch replacement, track lubrication, electrical fault diagnosis |
| 3.6L Pentastar V6 | Oil consumption check, rocker arm / EVAP purge valve replacement, timing chain inspection |
| Hybrid High-Voltage System | Battery pack diagnostics, eFlite transmission service, high-voltage safety isolation procedures |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does my 2017–2020 Pacifica shift harshly or shudder from the 9-speed transmission?
The 948TE 9-speed automatic is known for shudder and rough low-speed gear changes. The manual covers full diagnostic procedures, fluid specification and change intervals, valve body inspection, and TCM software update guidance to address these symptoms.
Does this manual cover the Pacifica Hybrid plug-in variant?
Yes. The Pacifica Hybrid shares the RU platform and 3.6L Pentastar V6 but adds dual electric motors, a 16 kWh lithium-ion battery, and the eFlite electrically variable transmission. All hybrid-specific high-voltage diagrams, battery service procedures, and eFlite transmission repair steps are included.
Are wiring diagrams and Uconnect infotainment schematics included?
Complete electrical coverage is provided, including circuit diagrams for engine management, ABS, airbags, power sliding doors, power liftgate, and Uconnect infotainment. Connector pinouts, ground distribution, and color-coded factory wiring schematics are all part of this manual.
What format is the manual?
The manual is delivered as a fully searchable PDF compatible with Windows, Mac, iOS, and Android devices. After purchase, download begins immediately and you retain lifetime re-download access.
