Factory Citroen AX Workshop Manual (1991–1998)
This is the same dealer-level ServiceBox software relied upon by authorized Citroen workshops to service and repair every AX variant sold between 1991 and 1998, including the battery-electric AX Electrique — a rare EV offering for its era.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.0L TU9, 1.1L TU1, 1.3L TU2, 1.4L TU3 |
| Electric | SA13 11 kW / 15 hp (AX Electrique) |
| Transmissions | 5-speed manual |
| Drive | FWD |
| Model Years | 1991–1998 |
| Badge Twins | N/A |
Common AX Repairs Covered
| System | Procedures |
|---|---|
| TU-Series Engine | Cam belt replacement, cylinder head gasket renewal, valve clearance adjustment |
| Suspension | Front strut replacement, rear torsion bar adjustment — a known wear item on high-mileage AX models |
| Electrical / AX Electrique | SA13 motor diagnostics, battery management system checks, charging circuit testing |
| Brakes | Front disc and rear drum service, handbrake cable adjustment, master cylinder overhaul |
Format & Delivery
Citroen ServiceBox dealer software delivered as a VMware Player virtual machine — NOT a PDF. Compatible with Windows 11, 10, 8, 7, Vista, XP, Mac, and Linux. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the software cover the AX GTi high-performance variant?
Yes. The software includes data for the AX GTi, which used the 1360cc TU3S engine producing around 100 hp. Full coverage includes engine management calibration, performance-spec brake procedures, and suspension geometry settings specific to the GTi trim.
Is the AX Electrique covered alongside the petrol models?
Absolutely. The AX Electrique used the SA13 electric motor rated at 11 kW (15 hp) and was one of Citroen’s earliest production EVs. The software includes dedicated diagnostic routines, motor removal and refitting procedures, and charging system troubleshooting for this variant alongside all petrol models.
Are interactive wiring diagrams included for electrical diagnosis?
Yes. The ServiceBox software provides color-coded, interactive circuit diagrams covering engine management, lighting, instrumentation, central locking, and auxiliary systems. Component locator tools identify connector positions and ground points — matching the same resources used by authorized Citroen dealers.
What format is the manual?
This is professional OEM dealer software, not a static PDF. It runs as a VMware Player virtual machine and is compatible with Windows, Mac, and Linux systems. Features include searchable databases, guided diagnostics, and interactive wiring diagrams — capabilities well beyond a conventional document.
