Factory Citroen C3 Picasso Workshop Manual (2009–2017)
This factory-level repair manual covers every C3 Picasso compact MPV sold in the US and global markets from the 2009 model year through the final 2017 production run, giving home mechanics and professional technicians identical reference material.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.2L, 1.4L VTi (EP3, 95 hp), 1.6L VTi (EP6, 120 hp), 1.6L THP turbo |
| Diesel | 1.6L HDi 8V (DV6, 90 hp), 1.6L HDi 16V (DV6C, 110 hp) |
| Transmissions | 5-speed manual, 6-speed manual, EGS6 automated manual |
| Drive | FWD |
| Model Years | 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017 |
| Badge Twins | N/A |
Common C3 Picasso Repairs Covered
| System | Procedures |
|---|---|
| EP6 / THP Timing Chain | Timing chain tensioner replacement and chain stretch diagnosis on 1.6L THP units — a known premature wear issue |
| BSI Multiplex Unit | CAN bus fault diagnosis, BSI reset procedure, and connector corrosion repair |
| EGS6 Automated Transmission | Clutch actuator calibration, fluid change, and fault code retrieval for hesitation and jerky shifts |
| Suspension | Front lower arm bush replacement and rear torsion beam inspection — frequently needed after high-mileage use |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the 1.6L THP timing chain issue documented in this manual?
Yes. The EP6 1.6L THP engine is well known for timing chain tensioner wear, particularly on early builds. The manual includes full disassembly sequences, tensioner part specifications, torque values, and updated replacement procedures applicable to all C3 Picasso THP variants from 2009 onward.
Does this manual cover the PSA PF1 platform details shared with other models?
The C3 Picasso rides on the PSA PF1 platform, shared with several European-market PSA group vehicles. All platform-specific suspension geometry data, subframe torque specs, and steering rack procedures included here are specific to the C3 Picasso body and drivetrain configuration.
Are wiring diagrams and BSI electrical schematics included?
Full electrical coverage is provided, including CAN bus network diagrams, BSI multiplex unit pinouts, engine management circuits, lighting, climate control, central locking, and instrument cluster schematics. Wire color codes and connector locations are clearly identified throughout.
What format is the manual?
The manual is delivered as a searchable PDF file. It is compatible with Windows, Mac, iOS, and Android devices. Individual pages or complete chapters can be printed for bench use, and the file may be saved across multiple devices for permanent access.
