Factory Ford Transit Workshop Manual (1994-2014)
This is the official OEM dealer-level workshop software used by authorized Ford service centers to diagnose, service, and repair the Transit van across two decades of North American and global production – covering every chassis code from MK5 through MK7.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.0L (1994-2003), 2.3L Duratec (2000-2014) |
| Diesel | 2.5L, 2.5L Turbo (1994-2003); 2.0L Duratorq TDCi (ABFA/FIFA), 2.2L Duratorq TDCi (PGFA/PGFB/QVFA/QWFA), 2.4L Duratorq TDCi (JXFA/PHFA/H9FA), 3.2L Duratorq TDCi (SAFA) (2000-2014) |
| Transmissions | 5-speed MT75 manual, 5-speed MT75/VXT75, 6-speed MT82/VMT6 manual, 5-speed Durashift-EST automated manual |
| Drive | RWD; Left- and right-hand drive configurations covered |
| Model Years | 1994-2014 |
| Badge Twins | N/A |
Common Transit Repairs Covered
| System | Procedures |
|---|---|
| 2.4L TDCi Turbocharger | Turbo removal, inspection, wastegate actuator testing, boost leak diagnosis, and replacement torque specs |
| MT75 Gearbox | 5th gear selector fork wear repair – a well-documented Transit failure point – including full strip-down and rebuild procedures |
| Rear Axle & Brakes | Rear drum brake service, wheel cylinder replacement, axle bearing inspection, and ABS sensor replacement |
| Cooling System | Coolant leak diagnosis, thermostat replacement, water pump service, and EGR cooler inspection procedures |
Format & Delivery
Dealer software (NOT a PDF). This is the same interactive OEM platform used by Ford-authorized workshops, featuring searchable diagnostics, zoomable wiring diagrams, integrated EPC, and component locators. Compatible with Windows XP through Windows 11, Mac, and Linux. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this cover the MK7 Transit (V347/V348) 3.2L TDCi?
Yes. The 3.2L Duratorq TDCi (engine code SAFA), fitted to heavier-duty MK7 Transit variants on the V347/V348 platform, is fully covered – including fuel system calibration, DPF service procedures, and glow plug replacement sequences.
Which Transit body styles and wheelbases are included?
Coverage extends across all Transit configurations sold between 1994 and 2014: panel van, kombi, chassis cab, double cab, and minibus body styles in short, medium, long, and extended long wheelbase configurations. Both low and high roof variants are included.
Are wiring diagrams included for the Transit’s electrical systems?
Yes. The software includes fully interactive wiring diagrams covering engine management, ABS/traction control, airbag systems, central locking, lighting circuits, HVAC controls, and multiplexed body electronics – complete with connector pinouts, wire color codes, ground locations, and splice identification.
What format is the manual?
This is NOT a PDF – it is professional OEM Ford dealer software delivered as an installable application. It provides the same diagnostic procedures, torque specifications, illustrated repair steps, and parts catalog access that Ford dealerships rely on. It installs on Windows (XP through 11), Mac, and Linux systems.
