Factory GMC Canyon Workshop Manual (2014-2017)
This factory-level service manual covers every second-generation GMC Canyon built for the US market between 2014 and 2017, providing technicians and serious DIYers with complete repair procedures, wiring diagrams, and torque specifications.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Gasoline | 2.5L LCV inline-4, 3.6L LGX V6 |
| Diesel | 2.8L LWN Duramax turbo-diesel inline-4 |
| Transmissions | 6-speed manual, 6-speed automatic (6L50), 8-speed automatic (8L45) |
| Drive | RWD, 4WD |
| Model Years | 2014, 2015, 2016, 2017 |
| Badge Twins | Chevrolet Colorado (GMT 31XX platform) |
Common Canyon Repairs Covered
| System | Procedures |
|---|---|
| 3.6L V6 Timing Chain | Timing chain wear diagnosis, tensioner replacement, and full chain set service for the LGX V6 |
| 8L45 Transmission Shudder | Torque converter shudder diagnosis, fluid and filter service, TCM recalibration procedures |
| Brake System | Front and rear caliper overhaul, rotor resurfacing specs, parking brake adjustment, ABS module diagnosis |
| HVAC / A/C | Compressor replacement, refrigerant charge specifications, blower motor and blend door actuator service |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the 2014-2017 Canyon have known timing chain issues?
The 3.6L LGX V6 can develop timing chain stretch and tensioner wear, often signaled by a rattling noise at cold start. This manual includes full timing chain inspection criteria, tensioner replacement procedures, and OEM torque values to carry out the repair correctly.
Is the Chevrolet Colorado covered by this same manual?
The second-generation GMC Canyon and Chevrolet Colorado share the GMT 31XX platform and are mechanically near-identical. While this manual is specifically published under the GMC Canyon designation, the majority of procedures, specifications, and diagrams are directly applicable to the equivalent Colorado of the same model years.
Are wiring diagrams and electrical diagnostics included?
Yes. The manual contains full circuit diagrams covering the engine management system, body control module, lighting, infotainment, power accessories, trailer wiring, and ground/power distribution schematics. Connector pinouts and DTC diagnostic procedures are included for all major electrical systems.
What format is the manual?
The manual is delivered as a fully searchable PDF document. After purchase you can download it immediately and access it on any Windows, Mac, Android, or iOS device using a standard PDF reader. Individual pages or sections can be printed as needed for shop use.
