Description
Factory Holden Monaro Workshop Manual (2001-2006)
This is the same OEM dealer software used by authorized Holden service centers across Australia and export markets, covering every Monaro variant from the V2 through the final VZ series produced between 2001 and 2006.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.8L Ecotec V6 (L36/L67 supercharged), 5.7L Gen III V8 (LS1), 6.0L Gen IV V8 (LS2) |
| Diesel | N/A |
| Transmissions | Tremec T56 6-speed manual; 4L60-E / 4L65-E 4-speed automatic |
| Drive | RWD |
| Model Years | 2001, 2002, 2003, 2004, 2005, 2006 |
| Badge Twins | Vauxhall Monaro VXR (UK export); Pontiac GTO (US market, 2004-2006) |
Common Monaro Repairs Covered
| System | Procedures |
|---|---|
| LS1/LS2 Valve Train | Lifter replacement, timing cover seal R&R, cam phaser inspection on Gen IV LS2 |
| T56 Gearbox | 3rd/4th gear synchronizer replacement, shifter bushing wear, gear oil specification and fill |
| Rear Differential | Pinion seal replacement, LSD clutch pack service, backlash and bearing preload adjustment |
| ABS / Traction Control | Wheel speed sensor diagnostics, EBCM fault code retrieval, brake pressure modulator bleeding |
Format & Delivery
Dealer software – VMware Player virtual machine (NOT a PDF). Compatible with Windows 11, 10, 8, 7, Vista, XP, Mac, and Linux. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this software cover both the V2 and VZ Monaro series?
Yes. The V2 series (2001-2003) covering CV6, CV8, and CV8-R variants and the VZ series (2004-2006) covering the CV8 and CV8-Z are all fully supported, including unique specifications for each platform such as the introduction of the LS2 engine in 2004.
Is the Pontiac GTO covered since it shares the same platform?
The Pontiac GTO (2004-2006) is a direct US-market rebadge of the VZ Monaro and shares the same Gen III/IV V8 powertrains and Tremec T56 gearbox. While this software is authored for the Holden Monaro, the mechanical procedures and wiring data are substantially applicable to GTO service work.
Are full wiring diagrams included for the LS2-equipped models?
Yes. Interactive, color-coded wiring diagrams cover all electrical systems on both LS1 and LS2 variants, including the engine management system, ABS/traction control circuits, HVAC, lighting, central locking, and the security system introduced on later VZ models.
What format is the manual?
This is dealer-grade OEM software delivered as a VMware Player virtual machine – it is NOT a PDF. It runs on Windows (11 through XP), Mac, and Linux and features searchable repair procedures, diagnostic flowcharts, zoom-capable diagrams, and integrated technical service bulletins identical to those used by authorized Holden dealerships.
