Factory Hyundai Grandeur Workshop Manual (2014–2017)
This official factory-level service manual covers the fifth-generation Hyundai Grandeur HG facelift — the same executive sedan sold in the US market as the Hyundai Azera — giving American owners and technicians full manufacturer repair data in English.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.0L Lambda-II V6 (G6DG); 3.3L Lambda-II GDI V6 (G6DH) |
| Diesel | N/A |
| Transmissions | 6-speed automatic with Shiftronic manual mode |
| Drive | FWD |
| Model Years | 2014, 2015, 2016, 2017 |
| Badge Twins | Hyundai Azera (North America) |
Common Grandeur Repairs Covered
| System | Procedures |
|---|---|
| GDI Fuel System | High-pressure fuel pump inspection and replacement; GDI injector cleaning and flow testing for carbon buildup on intake valves common to Lambda-II direct-injection engines |
| 6-Speed Automatic Transmission | Fluid and filter service; solenoid valve diagnosis; valve body removal and reinstallation with full torque specs |
| Steering & Suspension | Electronic power steering (MDPS) calibration; front strut and rear multi-link component replacement; alignment specifications |
| Electrical / Smart Junction Box | BCM and SJB wiring diagram tracing; airbag SRS fault diagnosis; HVAC blend door actuator replacement procedure |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the Hyundai Azera the same vehicle as the Grandeur HG?
Yes. Hyundai marketed the fifth-generation Grandeur HG as the Azera for the North American market. The engineering, chassis codes, and powertrains are identical, so this manual applies directly to US-spec Azera models from the same 2014–2017 production run.
Does the 3.3L Lambda-II GDI engine have a known carbon buildup problem?
Direct-injection V6 engines like the G6DH are prone to carbon accumulation on intake valves because fuel is injected directly into the cylinder rather than over the intake ports. This manual includes the full fuel system and induction service procedures needed to address that issue, along with injector flow specifications.
Are wiring diagrams and electrical schematics included?
Yes. The manual provides complete vehicle electrical documentation — engine management, ABS/ESC, SRS airbag, HVAC controls, lighting, audio, and power accessories — with color-coded connector pinouts and ground point locations to support systematic fault diagnosis.
What format is the manual?
The manual is delivered as a PDF file, compatible with Windows, Mac, Linux, iOS, and Android. It is fully searchable by keyword and individual pages can be printed for bench use. No subscription or internet connection is required after download.
