Factory Hyundai i30 Workshop Manual (2007–2012)
This factory-level service manual covers the first-generation Hyundai i30 (FD chassis), giving US-based owners and technicians the complete repair and diagnostic data needed to service every system from engine to body electronics.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.4L Gamma G4FA (105 hp), 1.6L Gamma G4FC (122 hp), 2.0L Beta G4GC (143 hp) |
| Diesel | 1.6L U-II CRDi D4FB (90–115 hp), 2.0L D-II CRDi D4EA (140 hp) |
| Transmissions | 5-speed manual M5CF2, 6-speed manual, 4-speed automatic A4CF2 |
| Drive | FWD |
| Model Years | 2007, 2008, 2009, 2010, 2011, 2012 |
| Badge Twins | Hyundai Elantra Touring (i30CW wagon, North America) |
Common i30 Repairs Covered
| System | Procedures |
|---|---|
| Timing Chain (G4FC/G4GC) | Tensioner inspection, chain stretch diagnosis, replacement procedure with torque specs |
| D4FB Diesel Fuel System | High-pressure pump removal, injector coding, DPF regeneration procedures |
| A4CF2 Automatic Transmission | Fluid flush, solenoid replacement, shift-quality fault diagnosis |
| Front Suspension | Strut bearing replacement, lower control arm bushing service, wheel alignment specs |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does my i30’s timing chain rattle on cold starts?
The 1.6L G4FC and 2.0L G4GC engines are known for timing chain tensioner wear, especially on higher-mileage examples. The manual includes the full tensioner inspection procedure, chain slack measurement specifications, and step-by-step replacement instructions with all required torque values.
Is the Hyundai Elantra Touring the same vehicle as the i30CW?
Yes. The i30CW wagon was sold in the United States and Canada as the Hyundai Elantra Touring from 2009–2012. Both share the identical FD platform, powertrain, and body structure, so this manual applies directly to Elantra Touring service work as well.
Does the manual cover the diesel CRDi engines sold in export markets?
Yes. Complete service data is included for both the 1.6L D4FB U-II CRDi and the 2.0L D4EA D-II CRDi diesel engines, covering fuel injection system service, glow plug replacement, EGR maintenance, and DPF-related procedures.
What format is the manual?
The manual is a PDF file delivered via instant download after purchase. It is fully searchable, supports zoom-in viewing of diagrams, and is compatible with Windows, Mac, Linux, iOS, and Android devices. Pages can be printed as needed for workshop use.
