Factory Jaguar E-Type Series 3 Workshop Manual (1971–1974)
This factory-level service manual delivers complete repair and maintenance coverage for the Jaguar E-Type Series 3 — one of the most celebrated sports cars ever sold on the US market. All procedures apply to the 1971–1974 production run across both available body configurations.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 5.3L Jaguar all-aluminum SOHC V12 (~272 hp) |
| Diesel | N/A |
| Transmissions | 4-speed manual; Borg-Warner Model 12 3-speed automatic |
| Drive | RWD |
| Model Years | 1971, 1972, 1973, 1974 |
| Body Styles | 2-door Roadster; 2+2 Fastback Coupe |
| Badge Twins | N/A |
Common E-Type Series 3 Repairs Covered
| System | Procedures |
|---|---|
| V12 Cooling System | Thermostat replacement, radiator flush, cooling fan diagnostics — the Series 3 V12 is known for running hot in traffic |
| Lucas Electrical System | Wiring harness inspection, ignition circuit testing, charging system diagnosis, and connector restoration |
| Carburetion / Fuel Delivery | Zenith-Stromberg carburettor synchronization, fuel pump service, and fuel line inspection |
| Independent Rear Suspension | Hub carrier removal, driveshaft u-joint replacement, wheel bearing inspection and adjustment |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the manual cover the V12 overheating issue common to the Series 3?
Yes. The 5.3L V12 in the Series 3 E-Type has a well-documented tendency to run hot, especially at low speeds. This manual includes complete cooling system diagnostics, thermostat specifications, coolant capacity data, water pump service procedures, and electric cooling fan circuit testing to address this issue thoroughly.
Are both the Roadster and 2+2 Coupe body styles covered?
Both body styles are included. The Series 3 E-Type was offered exclusively as a 2-door Roadster and a 2+2 Fastback Coupe — this manual addresses chassis, body, and interior procedures for each variant. Left-hand and right-hand drive configurations are also documented.
Does this manual include wiring diagrams for the Lucas electrical system?
Complete wiring schematics for the Lucas electrical system are included, covering ignition, lighting, instrumentation, charging circuit, and accessory wiring. Wire color codes and connector locations are identified to streamline fault diagnosis on these aging but repairable electrical systems.
What format is the manual?
This manual is a PDF document. After purchase, you receive an instant download link. The file is fully searchable and can be viewed on any Windows PC, Mac, tablet, or smartphone. Pages may also be printed for bench reference during repairs.
