Factory Jaguar X-Type Workshop Manual (2001–2009)
This factory-level repair manual covers the complete X400-platform Jaguar X-Type lineup sold in North America and worldwide, giving US owners and independent shops the same depth of technical data used by Jaguar dealership technicians.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.0L AJ-V6, 2.5L AJ-V6, 3.0L AJ27 V6 |
| Diesel | 2.0L Duratorq TDCi, 2.2L Duratorq TDCi |
| Transmissions | 5-speed MT75 manual, 6-speed MMT6 manual, 5-speed JATCO automatic, 6-speed AWF21 automatic |
| Drive | FWD; AWD (2.5L & 3.0L petrol variants) |
| Model Years | 2001–2009 (pre-2007 facelift body; facelift exterior trim not covered) |
| Badge Twins | N/A |
Common X-Type Repairs Covered
| System | Procedures |
|---|---|
| AWD Transfer Case & Haldex Coupling | Fluid service, unit R&R, and fault diagnosis for the rear-drive coupling — a frequent X-Type maintenance item |
| Duratorq TDCi Fuel System | High-pressure injector removal/installation, common-rail pressure testing, and EGR valve cleaning |
| Cooling System | Thermostat housing replacement, coolant flush, and pressure testing — V6 models are prone to coolant loss at the housing |
| Electrical & HVAC | Wiring diagrams, ABS module diagnostics, climate control actuator replacement, and connector pinout references |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the manual cover both the saloon and estate (wagon) body styles?
Yes. Both the four-door X-Type saloon and the five-door estate wagon — introduced for the 2004 model year — are fully covered. Note that exterior body panel procedures specific to the revised 2007 facelift styling are not included, though all mechanical and electrical systems remain applicable to facelift vehicles.
Is the X-Type related to any other Ford Motor Company platform?
Yes. The X400-platform X-Type shares its front-wheel-drive architecture with the Ford Mondeo Mk3, which informed the AWD driveline layout. This is why diesel engines are Ford-sourced Duratorq TDCi units and several manual transmissions (MT75) are shared with Ford applications — a useful detail when sourcing parts in the US.
Are wiring diagrams included for the ABS and traction control systems?
Full electrical documentation is included, covering ABS/DSC wiring, connector pinouts, ground point locations, engine management schematics, climate control circuits, lighting, central locking, and instrument cluster diagrams — everything needed to trace faults with a multimeter or scan tool.
What format is the manual?
The manual is a PDF file delivered by instant download after purchase. It is fully searchable and compatible with any PDF reader on Windows, Mac, iOS, Android, and Linux devices. Individual pages can be printed for bench use, and the file can be re-downloaded at any time at no extra charge.
