Factory Kia Carnival Workshop Manual (1998-2005)
This official factory-level workshop manual covers the first-generation Kia Carnival KV-II minivan sold across global markets from 1998 through 2005, giving US-based owners and technicians everything needed to service or rebuild this van at home or in the shop.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.5L Sigma V6 |
| Diesel | 2.9L J3 turbodiesel |
| Transmissions | 5-speed manual, 5-speed automatic |
| Drive | FWD |
| Model Years | 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005 |
| Badge Twins | Kia Sedona (North America), Hyundai Entourage (related platform) |
Common Carnival Repairs Covered
| System | Procedures |
|---|---|
| Sliding Door Mechanism | Roller and latch inspection, cable adjustment, and track lubrication for the notoriously stiff first-gen power sliding doors |
| Cooling System | Thermostat replacement, coolant flush, water pump R&R on the 3.5L V6 – a known weak point on high-mileage units |
| Brake System | Front and rear pad/rotor replacement, ABS modulator testing, brake fluid flush procedures |
| Electrical / Wiring | Full circuit diagrams for engine management, climate control, central locking, and lighting with connector pin assignments |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the Kia Carnival the same vehicle as the Kia Sedona sold in the US?
Yes. The first-generation Kia Carnival (chassis KV-II) was introduced to North America under the Sedona name starting with the 2002 model year. This manual covers both naming conventions and all trim levels produced during the 1998-2005 production run.
Does the manual cover the 2.9L J3 diesel engine?
Yes. Complete coverage is included for the turbocharged 2.9L J3 diesel, including injection system diagnostics, timing belt service intervals, turbocharger inspection, and full overhaul specifications with torque values.
Are wiring diagrams included for the ABS and airbag systems?
Yes. The electrical section provides detailed schematics for the ABS modulator, SRS airbag circuits, power windows, central locking, and HVAC controls, along with ground point locations and connector pin-out charts to speed up fault diagnosis.
What format is the manual?
This manual is a PDF file. After purchase, you can download it immediately and re-download it at any time. The fully searchable document is compatible with any standard PDF reader on Windows, Mac, iOS, Android, or Linux devices.
