Description
Factory Mazda 3 Workshop Manual (2004–2009)
This factory-sourced service manual covers every first-generation Mazda 3 sold in the US market from 2004 through 2009, including the high-performance Mazdaspeed3 variant with its turbocharged powerplant.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.0L FL inline-4, 2.3L L3 MZR inline-4, 2.3L L3 turbo DISI (Mazdaspeed3) |
| Diesel | N/A |
| Transmissions | 4-speed automatic FN4A-EL, 5-speed automatic FS5A-EL, 5-speed manual G35M-R, 6-speed manual A26M-R |
| Drive | FWD |
| Model Years | 2004, 2005, 2006, 2007, 2008, 2009 |
| Badge Twins | Mazda Axela (Japan domestic market) |
Common Mazda 3 Repairs Covered
| System | Procedures |
|---|---|
| Engine — Timing Chain | Timing chain tensioner inspection and replacement on 2.3L L3 engines prone to rattle at cold start |
| Suspension — Front Struts | Strut and spring replacement addressing known premature wear and clunking on BK-chassis models |
| Brake System | Rear caliper slide pin service and rotor replacement; rear caliper seizure is a documented issue on 2004–2009 models |
| Cooling System | Thermostat and coolant temperature sensor replacement; overheating diagnosis and radiator flush procedures |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this manual cover the Mazdaspeed3 turbocharged model?
Yes. The 2.3L L3 DISI turbocharged engine fitted to the Mazdaspeed3 is fully documented, including boost system diagnostics, intercooler service, and the 6-speed manual A26M-R transmission rebuild procedures.
Is the Mazda Axela covered by this manual?
The first-generation Mazda 3 (BK platform) was sold in Japan as the Mazda Axela. Because both nameplates share identical engineering, the factory procedures in this manual apply directly to Axela variants as well.
Are complete wiring diagrams included for the ABS and airbag systems?
Yes. Electrical coverage includes full circuit diagrams for ABS, supplemental restraint (airbag), engine management, climate control, and power accessories — with connector locations, wire color codes, and systematic fault-tracing procedures.
What format is the manual?
The manual is delivered as a PDF file, compatible with Windows, Mac, iOS, and Android devices using any standard PDF reader. You can search by keyword, zoom into diagrams, and print any pages you need at the bench.
