Factory Mazda RX-7 Workshop Manual (1992–2002)
This is the official factory-level repair manual for the third-generation Mazda RX-7 FD3S, covering every model year sold in the United States and abroad from 1992 through 2002. Whether you’re chasing a boost leak on the sequential twin-turbo system or rebuilding the rear suspension geometry, this document delivers manufacturer-grade procedures from start to finish.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.3L 13B-REW twin-turbocharged rotary (sequential twin-turbo) |
| Diesel | N/A |
| Transmissions | 5-speed manual, 4-speed automatic |
| Drive | RWD |
| Model Years | 1992–2002 |
| Badge Twins | N/A |
Common RX-7 Repairs Covered
| System | Procedures |
|---|---|
| Rotary Engine | Apex seal inspection and replacement, rotor housing resurfacing, eccentric shaft rebuild |
| Cooling System | Thermostat housing replacement, radiator coolant flush, overheating diagnosis — a well-known FD3S failure point |
| Sequential Twin-Turbo | Turbocharger actuator adjustment, vacuum line inspection, boost pressure testing and solenoid replacement |
| Fuel & Ignition | Fuel injector flow testing, ignition coil pack replacement, timing adjustment per factory specification |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does the 13B-REW overheat and how does this manual help?
The FD RX-7’s 13B-REW is highly sensitive to cooling system neglect — blocked thermostats, degraded coolant, and air pockets in the system are leading causes of overheating and subsequent engine damage. This manual includes complete coolant system diagrams, bleeding procedures, thermostat replacement steps, and water pump service intervals to help you stay ahead of this well-documented issue.
Which trim levels and series does this manual cover?
Coverage spans the entire FD3S third-generation lineup, including Series 6, 7, and 8 variants. Trim levels covered include Type RB, Type RB-S, Type R, Type RS, Type RZ, Touring X, and the limited Spirit R edition. Both JDM and export configurations are addressed throughout the document.
Are apex seal replacement procedures included?
Yes. The engine section provides full disassembly and reassembly procedures for the 13B-REW rotary unit, including apex seal removal, gap measurement, housing inspection for scoring, and installation torque sequences. This is one of the most critical maintenance tasks specific to rotary ownership and is covered in detail.
What format is the manual?
The manual is delivered as a PDF file immediately after purchase. It is fully searchable by keyword and compatible with all major operating systems and devices, including Windows, Mac, Linux, iOS, and Android. Individual pages or entire sections can be printed for use in your shop.
