Description
Factory Mercedes-AMG GLE 63 4Matic+ Workshop Manual (2020-2022)
This is the official factory-level service manual for the W167-platform Mercedes-AMG GLE 63 4Matic+, covering the 2020 through 2022 model years sold in the US market. Technicians and serious enthusiasts will find the same detailed procedures, wiring schematics, and torque specifications used at authorized Mercedes-AMG dealerships.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | M177 4.0L twin-turbocharged V8 (571 hp GLE 63; 603 hp GLE 63 S) |
| Diesel | N/A |
| Transmissions | AMG Speedshift TCT 9-speed automatic |
| Drive | 4Matic+ performance AWD |
| Model Years | 2020, 2021, 2022 |
| Badge Twins | GLE 63 S 4Matic+ (W167 platform) |
Common GLE 63 Repairs Covered
| System | Procedures |
|---|---|
| M177 V8 Cooling | Coolant pipe and water pump service — a known leak point on the M177 engine |
| Air Suspension (AIRMATIC) | Compressor replacement, air strut diagnosis, and height sensor calibration |
| Brake System | AMG high-performance brake rotor and caliper replacement, brake fluid flush procedures |
| Electrical / MBUX | Wiring diagrams and diagnostic steps for MBUX infotainment, ADAS modules, and body control units |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does the M177 V8 in the GLE 63 sometimes develop coolant leaks?
The M177 4.0L twin-turbo V8 uses plastic coolant distribution pipes that can become brittle over time, particularly around the rear of the engine. This manual covers complete removal and replacement procedures for these pipes along with water pump service, pressure testing, and torque specifications to prevent recurrence.
Does this manual cover both the GLE 63 and GLE 63 S variants?
Yes. Both the standard GLE 63 4Matic+ (571 hp) and the higher-output GLE 63 S 4Matic+ (603 hp) are fully documented. Both share the W167 chassis and M177 engine family, so all procedures, wiring diagrams, and specifications in this manual apply to either variant across the 2020-2022 model years.
Is the AIRMATIC air suspension system covered in detail?
Absolutely. The manual includes full diagnostic and repair procedures for the AIRMATIC adaptive air suspension fitted to the GLE 63, covering the compressor unit, air supply lines, individual air struts, ride-height sensors, and electronic control module programming steps.
What format is the manual?
This manual is provided as a PDF file. After purchase you receive an instant download link, and the file can be opened on any Windows, Mac, or mobile device using a standard PDF reader. Pages can be printed individually for bench use, and the full-text search function makes locating specific procedures quick and straightforward.
