Factory Mercedes CLA Class C117 Workshop Manual (2013–2019)
This is the factory-level service manual for the Mercedes-Benz CLA Class C117, covering every production variant sold in the US market from 2013 through 2019 — from the entry-level CLA 180 to the performance-tuned Mercedes-AMG CLA 45.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | M270 1.6L turbo (122hp–156hp), M270 2.0L turbo (211hp), M133 2.0L turbo AMG (360hp–381hp) |
| Diesel | OM607 1.5L, OM651 2.1L (CLA 200d, CLA 220d) |
| Transmissions | 6-speed manual, 7G-DCT dual-clutch automatic |
| Drive | FWD, AWD (4MATIC) |
| Model Years | 2013–2019 |
| Badge Twins | N/A |
Common CLA Class Repairs Covered
| System | Procedures |
|---|---|
| 7G-DCT Dual-Clutch Transmission | Clutch pack replacement, TCU adaptation reset, fluid change intervals, shudder diagnosis |
| M270/M133 Engine | Timing chain tensioner inspection, oil consumption diagnosis, turbocharger wastegate adjustment |
| Brakes & ESP | Brake pad and rotor replacement, ESP sensor calibration, ABS module fault diagnosis |
| Electrical & COMAND | Wiring diagram tracing, infotainment COMAND system faults, airbag circuit testing, body control module diagnosis |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the AMG CLA 45 covered in this manual?
Yes. The Mercedes-AMG CLA 45 (C117) is fully covered, including the M133 2.0L turbocharged four-cylinder producing 360hp to 381hp depending on model year. AMG-specific procedures for the performance braking system, 4MATIC AWD hardware, and sport-tuned suspension are all included.
Does this manual cover both FWD and AWD variants?
Yes. Standard CLA models use front-wheel drive, while 4MATIC variants add Mercedes’s all-wheel-drive system. The manual includes separate sections for the front and rear axle assemblies, transfer case, and 4MATIC-specific driveline components.
Are the 7G-DCT transmission overhaul procedures included?
Full 7G-DCT dual-clutch automatic transmission coverage is included — fluid specifications, clutch adaptation resets, valve body service, and complete disassembly/reassembly torque specifications. The 6-speed manual gearbox is covered in equal depth.
What format is the manual?
This manual is delivered as a PDF file immediately after purchase. It is fully searchable, printable, and compatible with any device running a standard PDF reader — including Windows and Mac computers, tablets, and smartphones.
