Factory Mercedes S Class W140 / C140 Workshop Manual (1992–1999)
This official factory-level workshop manual covers every S Class sedan and coupe produced on the W140/C140 platform from 1992 through 1999, giving US-based technicians and owners the same repair depth used by Mercedes-Benz dealer service departments.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | M104 inline-6 (2.8L, 3.2L), M119 V8 (4.2L, 5.0L), M120 V12 (6.0L) |
| Diesel | OM603 inline-6, OM606 turbodiesel |
| Transmissions | 722.3, 722.5, 722.6 automatic |
| Drive | RWD |
| Model Years | 1992–1999 |
| Badge Twins | S280, S300, S320, S350, S420, S500, S600 (W140); CL420, CL500, CL600 (C140) |
Common S Class W140 Repairs Covered
| System | Procedures |
|---|---|
| Air Suspension | Airmatic strut replacement, compressor diagnosis, ride-height sensor calibration |
| 722.6 Transmission | Valve body service, conductor plate replacement, fluid and filter change intervals |
| M120 V12 Timing | Timing chain guide replacement, tensioner inspection, chain stretch diagnosis |
| Electrical / Central Locking | Vacuum pump testing, door actuator replacement, wiring harness fault tracing |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this manual cover both the W140 sedan and C140 coupe?
Yes. The W140 sedan variants — S280, S300, S320, S350, S420, S500, and S600 — are fully covered, including short and long wheelbase configurations. The C140 coupe series, marketed as the CL420, CL500, and CL600 after the 1996 model year, is equally documented with coupe-specific body and trim procedures.
Which automatic transmissions are covered in detail?
The manual addresses all three 722-family automatics fitted to the W140/C140: the older 722.3 and 722.5 units found in early production cars, and the electronically controlled 722.6 five-speed introduced in the mid-1990s. Rebuild procedures, conductor plate replacement, and shift adaptation reset instructions are included.
Are wiring diagrams included for the climate control and ABS systems?
Full wiring diagrams are provided for all major electrical systems, including the dual-zone climate control, ABS/ASR, central locking vacuum circuit, power windows, and instrument cluster. Connector pinouts, ground locations, fuse assignments, and wire color codes are clearly identified throughout.
What format is the manual?
The manual is a PDF file. After purchase you receive an instant download link, and the file can be accessed again at any time through lifetime re-download privileges. It is fully searchable and printable on any Windows, Mac, or mobile device.
