Factory Mitsubishi Eclipse Workshop Manual (2006–2012)
This is the official factory-level service manual for the fourth-generation Mitsubishi Eclipse, covering every DK2A and DK4A coupe and Spyder convertible sold in the US market from 2006 through 2012.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.4L 4G69 MIVEC I4, 3.8L 6G75 MIVEC V6 |
| Diesel | N/A |
| Transmissions | 4-speed automatic F4A4B, 5-speed automatic F5A5A, 5-speed manual F5M42, 6-speed manual F6MBA |
| Drive | FWD |
| Model Years | 2006, 2007, 2008, 2009, 2010, 2011, 2012 |
| Badge Twins | N/A |
Common Eclipse Repairs Covered
| System | Procedures |
|---|---|
| Timing Belt (4G69 / 6G75) | Belt and tensioner replacement with factory torque specs and alignment marks |
| MIVEC Variable Valve Timing | Solenoid cleaning, oil pressure diagnosis, and actuator replacement procedures |
| Automatic Transmission (F4A4B / F5A5A) | Fluid service, solenoid diagnosis, and complete overhaul with shift adaptation reset |
| Spyder Convertible Top | Hydraulic pump inspection, cylinder seal replacement, and folding mechanism adjustment |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the 6G75 V6 require timing belt replacement, and is it covered here?
Yes — the 3.8L 6G75 is an interference engine with a timing belt that Mitsubishi recommends replacing at 60,000-mile intervals. This manual includes the full factory procedure with tensioner specs, alignment marks, and torque values for both the 6G75 and the 2.4L 4G69.
Does this manual cover the Eclipse Spyder convertible as well as the coupe?
Both body styles are fully covered. The DK2A chassis codes apply to the coupe variants while DK4A designates the Spyder convertible. Unique Spyder-specific procedures — including the power-retractable soft top hydraulic system — are included alongside shared mechanical content.
Are MIVEC system diagnostics included for both engines?
Yes. The manual provides complete MIVEC variable valve timing diagnostics for both the 4G69 and 6G75, including oil control solenoid testing, fault code interpretation, and actuator replacement steps with factory specifications.
What format is the manual?
This manual is a PDF file, compatible with Windows, Mac, Linux, iOS, and Android devices. After purchase you receive an instant download link, and your access never expires — download again any time you need it.
