Factory Mitsubishi Mirage Workshop Manual (1995–2003)
This official factory-level repair manual covers the fourth-generation Mitsubishi Mirage sedan sold in the US and global markets from 1995 through 2003, delivering the same technical depth used by Mitsubishi-authorized service centers.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.5L 4G15 inline-4, 1.8L 4G93 inline-4 |
| Diesel | N/A |
| Transmissions | 5-speed manual, 4-speed automatic |
| Drive | FWD |
| Model Years | 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003 |
| Badge Twins | Dodge Colt (select markets), Eagle Summit, Mitsubishi Lancer (select markets) |
Common Mirage Repairs Covered
| System | Procedures |
|---|---|
| Timing Belt (4G15 / 4G93) | Replacement intervals, tensioner inspection, alignment marks, and torque specs — a known high-priority service item on these engines |
| Cooling System | Thermostat replacement, radiator flush, coolant hose inspection, and water pump R&R procedures |
| Brake System | Front disc pad and rotor service, rear drum adjustment, master cylinder overhaul, and brake line bleeding sequences |
| Electrical & Wiring | Full color-coded wiring diagrams, connector pinouts, charging system diagnostics, and fuel injection circuit troubleshooting |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Which chassis codes does this manual cover for the Mirage?
This manual covers the fourth-generation Mitsubishi Mirage 2-door and 4-door sedan variants under chassis codes CJ2A, CJ5A, CK2A, and CK5A, spanning the full 1995–2003 production run.
Is the Mitsubishi Mirage related to any badge-twin models sold in the US?
Yes. The fourth-generation Mirage shared its platform with the Dodge Colt and Eagle Summit in certain markets. Much of the drivetrain and electrical content in this manual applies to those rebadged variants as well.
Does the manual include timing belt replacement procedures for the 4G15 engine?
Yes. Complete timing belt service procedures for the 1.5L 4G15 and 1.8L 4G93 are included, covering tensioner replacement, belt routing diagrams, camshaft alignment marks, and all required torque specifications.
What format is the manual?
The manual is delivered as a PDF file compatible with Windows, Mac, tablets, and smartphones. The searchable text lets you locate specific torque values, part numbers, or repair procedures instantly, and you can print any pages needed for the shop floor.
