Factory Mitsubishi RVR Workshop Manual (2020-2024)
This is the official factory-level repair manual for the 2020-2024 Mitsubishi RVR, covering the first-generation third facelift across GA4W and GA2W chassis variants sold in the US and global markets as the Outlander Sport or ASX.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.6L 4A92, 2.0L 4B11 MIVEC, 2.0L 4J11 |
| Diesel | N/A |
| Transmissions | 5-speed manual, 6-speed CVT (INVECS-III) |
| Drive | FWD, AWD |
| Model Years | 2020, 2021, 2022, 2023, 2024 |
| Badge Twins | Mitsubishi ASX (international), Mitsubishi Outlander Sport (US) |
Common RVR Repairs Covered
| System | Procedures |
|---|---|
| CVT Transmission | INVECS-III fluid specification, belt/pulley inspection, shudder diagnosis and adjustment |
| Engine Cooling | Thermostat replacement, coolant flush, radiator fan relay diagnosis on 4B11 |
| Suspension | Front strut replacement, rear trailing arm bushing service, alignment specs |
| Electrical / TPMS | Wiring diagrams, TPMS sensor relearn procedure, ABS/ESC module fault diagnosis |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the CVT covered in full detail for the 2020-2024 RVR?
Yes. The manual includes complete INVECS-III CVT service procedures, covering fluid type and capacity specifications, pulley and belt inspection, Sport Mode calibration, and step-by-step diagnostic routines for common shudder or hesitation complaints on the 4B11 and 4J11 equipped models.
Does this manual cover the Outlander Sport and ASX badge twins?
It does. The 2020-2024 Mitsubishi RVR shares its GA4W/GA2W platform with the Outlander Sport sold in the United States and the ASX sold in international markets. This manual applies directly to all three nameplate variants built on that platform during the covered model years.
Are full wiring diagrams and electrical schematics included?
Yes. Comprehensive electrical diagrams cover the engine management system, ABS and stability control, SRS airbag circuits, HVAC controls, lighting, power accessories, and the keyless entry system – including connector pinouts, wire colors, and ground locations.
What format is the manual?
The manual is delivered as a PDF file. After purchase you receive an instant download link. The file is fully searchable and compatible with any standard PDF reader on Windows, Mac, tablet, or smartphone. Individual pages can be printed as needed for shop use.
