Factory Range Rover Sport L494 Workshop Manual (2018-2022)
This is the factory-level service manual for the second-generation Range Rover Sport L494 facelift, covering model years 2018 through 2022 sold in the US and worldwide markets. Every procedure from routine maintenance to full drivetrain overhaul is included in a single searchable PDF.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.0L Si4 turbocharged (P300), 3.0L V6 supercharged, 5.0L V8 supercharged (incl. SVR) |
| Diesel | 2.0L SD4, 3.0L SDV6 / TDV6 |
| Transmissions | ZF 8HP 8-speed automatic |
| Drive | AWD with Terrain Response transfer case |
| Model Years | 2018, 2019, 2020, 2021, 2022 |
| Badge Twins | N/A |
Common Range Rover Sport Repairs Covered
| System | Procedures |
|---|---|
| Air Suspension | Compressor replacement, air spring removal, height sensor calibration – a frequent L494 concern |
| 5.0L V8 Supercharger | Supercharger snout seal replacement, oil top-up procedure, timing chain service |
| ZF 8HP Transmission | Fluid and filter service, valve body removal, mechatronic unit replacement |
| Terrain Response / Transfer Case | Module diagnostics, actuator replacement, diff lock system fault-finding |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does the air suspension on the L494 Sport fail and is it covered in this manual?
The L494 Range Rover Sport air suspension is a known trouble area, with compressor failures and cracked air springs among the most reported issues after 60,000 miles. This manual includes complete air suspension diagnostics, compressor replacement steps, individual air spring R&R procedures, and height sensor recalibration sequences.
Which trim levels and performance variants are included?
All L494 facelift trims sold from 2018-2022 are covered: HSE, HSE Dynamic, Autobiography, and the high-performance SVR. Technical data is specific to each powertrain configuration, so SVR owners will find the correct 5.0L supercharged V8 torque specs and unique SVR suspension settings alongside standard Sport procedures.
Does the manual include wiring diagrams for the Terrain Response and infotainment systems?
Yes. Full circuit diagrams cover the Terrain Response 2 control modules, CAN bus networks, air suspension ECU, InControl Touch Pro infotainment wiring, lighting circuits, and all body control module schematics. Connector pinouts, wire colors, and ground locations are identified throughout.
What format is the manual?
The manual is a PDF file delivered immediately after purchase. It is fully searchable, printable, and compatible with Windows, macOS, iOS, Android, and any device with a PDF viewer. Re-downloads are available at any time through your account.
