Factory Renault Clio Workshop Manual (2013–2017)
This official-level repair manual covers the fourth-generation Renault Clio IV sold in the US and worldwide from 2013 through 2017, delivering dealership-grade procedures for every major system on the BH/KH platform.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 0.9 TCe (H4B), 1.2 16v (D4F), 1.2 TCe (H5F), 1.6 Turbo RS (M5M) |
| Diesel | 1.5 dCi (K9K) — multiple power outputs |
| Transmissions | 5-speed manual, 6-speed manual, 6-speed EDC dual-clutch automatic, CVT |
| Drive | FWD |
| Model Years | 2013, 2014, 2015, 2016, 2017 |
| Badge Twins | N/A |
Common Clio Repairs Covered
| System | Procedures |
|---|---|
| EDC Dual-Clutch Transmission | Clutch pack replacement, actuator calibration, shudder diagnosis on the DC4 EDC unit |
| 1.5 dCi K9K Engine | EGR valve cleaning/replacement, injector removal and return-flow testing, DPF regeneration |
| Suspension | Front strut replacement, rear torsion beam bush renewal, wheel alignment specifications |
| Electrical / Body | ABS sensor fault diagnosis, airbag system reset, central locking wiring pinouts and repair |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the EDC dual-clutch transmission fully covered in this manual?
Yes. The 6-speed EDC (DC4) is one of the Clio IV’s most serviced components. The manual includes complete actuator removal, clutch pack inspection, fluid change intervals, and the calibration procedure required after any internal work — essential reading given the known shudder issues on early units.
Which chassis codes and body styles does this manual cover?
Coverage spans all fourth-generation Clio IV variants built on the BH/KH platform, including the standard five-door hatchback (X98), the Clio Estate wagon, and the performance-oriented Clio RS (X98 RS). All trim levels from base Expression through top-spec Iconic and GT Line are included.
Does the manual include wiring diagrams for the ABS and airbag systems?
Full electrical schematics are included for every major circuit — engine management, ABS, supplemental restraints, climate control, and multimedia. Connector pinouts, wire color codes, and ground point locations are all documented, making fault-finding straightforward without a dealer scan tool.
What format is the manual?
The manual is a PDF file delivered immediately after purchase. It is fully searchable, printable, and compatible with any PDF reader on Windows, Mac, Linux, Android, or iOS — so you can pull it up in the garage on any device you have handy.
