Factory Subaru Tribeca Workshop Manual (2006-2014)
This official factory-level service manual delivers complete repair, maintenance, and wiring diagram coverage for the Subaru Tribeca sold across the US and Canadian markets from 2006 through 2014, encompassing both the original B9 Tribeca and the redesigned second-phase Tribeca.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.0L EZ30 H6 (2006-2007), 3.6L EZ36 H6 (2008-2014) |
| Diesel | N/A |
| Transmissions | 5-speed automatic with manual mode |
| Drive | Symmetrical AWD (standard) |
| Model Years | 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014 |
| Badge Twins | B9 Tribeca (2006-2007 designation) |
Common Tribeca Repairs Covered
| System | Procedures |
|---|---|
| EZ36 Oil Consumption | Piston ring inspection, valve stem seal replacement, oil consumption diagnosis per factory spec |
| Head Gasket (EZ30) | Boxer engine head gasket removal, resurfacing tolerances, retorque sequences |
| AWD Transfer Case | VTD/center differential fluid service, clutch pack inspection, transfer case disassembly |
| Front Strut & Suspension | Strut cartridge replacement, wheel bearing service, front subframe torque specifications |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this manual cover both the B9 Tribeca and the refreshed Tribeca models?
Yes. The manual spans the full production run from 2006 to 2014, covering the early B9 Tribeca badge used in 2006-2007 as well as the restyled Tribeca introduced for 2008. All trim levels – base, Limited, Premium, and Touring – on the WX platform are included.
Which engines are documented, and are rebuild procedures included?
Both Subaru boxer six-cylinder engines are fully covered: the EZ30 3.0L used in 2006-2007 models and the EZ36 3.6L fitted from 2008 onward. The manual includes complete disassembly sequences, clearance measurements, torque specs, and reassembly procedures for both engines, including guidance relevant to the known oil consumption issue on the EZ36.
Are wiring diagrams and electrical troubleshooting charts included?
Full electrical coverage is provided, including circuit diagrams for engine management, ABS, SRS airbag, HVAC, power accessories, and audio systems. Connector pin-out charts, wire color codes, ground locations, and diagnostic flowcharts are all documented to speed fault diagnosis.
What format is the manual?
The manual is delivered as a PDF file. After purchase you receive an instant download link; the file is fully searchable and printable, and compatible with Windows, Mac, iOS, Android, and all major tablets and phones using any standard PDF reader.
