Factory BYD S6 Workshop Manual (2011-2017, S6 / S6A / S6K)
The BYD S6 is one of the most globally-exported Chinese SUVs of the 2010s – sold across Asia, South America, Middle East, and beyond. This factory workshop manual covers all three S6 variants (S6, S6A, S6K) across the complete 2011-2017 production run, with two engine families, three transmission options, and comprehensive ABS/SRS/keyless-entry diagnostics.
Who This Manual Is For
BYD S6 owners doing home-garage work, independent workshops in Asia and South America servicing BYD vehicles, and technicians cross-referencing the BYD-specific engine codes (483QB, 488QA) and gearbox codes (5T19, 6T25, 6DT35).
Model Variant Coverage
| Variant | Details |
|---|---|
| BYD S6 | Kerb mass 1620 kg, 5T19 5-speed manual transmission |
| BYD S6A | Kerb mass 1665 kg, BYD6T25 6-speed manual transmission |
| BYD S6K | Kerb mass 1695 kg, BYD6DT35 6-speed automatic transmission |
All three: 5-door SUV, integral body construction, front-engine, front-wheel drive, 5-seat layout.
Powertrain Coverage
| Engine | Specifications |
|---|---|
| BYD483QB 1.991L | 4-cyl, 83×92mm, 9.6:1 CR, 95 kW @ 5800 rpm, 172 Nm @ 4750 rpm, EFI spark ignition |
| BYD488QA 2.362L | 4-cyl, 88×96mm, 9.8:1 CR, 118 kW @ 5800 rpm, 229 Nm @ 4000 rpm, EFI spark ignition |
Transmission Coverage
| Gearbox | Ratios |
|---|---|
| 5T19 5-speed manual (S6) | 3.583 / 1.947 / 1.379 / 1.030 / 0.767, final 4.333 |
| BYD6T25 6-speed manual (S6A) | 3.769 / 2.087 / 1.324 / 0.977 / 0.975 / 0.814, Rev 4.549 |
| BYD6DT35 6-speed automatic (S6K) | 3.462 / 2.05 / 1.3 / 0.902 / 0.914 / 0.756, Rev 3.989 |
Key Systems Covered
| System | Depth |
|---|---|
| ABS Hydraulic Dual-Pipe | Full diagnostic flow, customer fault-analysis forms, DTC tables, ECU pin definitions |
| SRS Airbag | Driver and passenger modules, SRS ECU, front/side crash sensors, block diagrams |
| Keyless Entry / Intelligent Key | Antennas, micro-switches, RF receiver, CAN network integration |
| Automatic Climate Control | R134a refrigerant (600±50g), compressor, condenser, sensors, diagnostic tables |
| Chassis & Suspension | McPherson front, three-link rear, pinion-and-rack hydraulic steering |
| Electrical | 12V neg-earth, 14V/110A alternator, 70Ah battery, CAN bus, multimedia, combination instrument |
Fluid Capacities
| Fluid | Capacity |
|---|---|
| Engine oil (483QB with filter) | 3.3 L |
| Engine oil (488QA with filter) | 4.3 L (5.0 L net fill) |
| Power steering | 1.1 L |
| Clutch / brake | 0.8 L |
| Coolant | 7.1 L |
| Fuel tank | 70 L (92 unleaded or above) |
Format & Delivery
PDF (~68 MB), searchable text, English language. Compatible with every OS and device. Instant download; lifetime re-downloads.
Frequently Asked Questions
Which variant do I have – S6, S6A, or S6K?
By transmission and kerb mass: S6 = 5-speed manual / 1620 kg; S6A = 6-speed manual / 1665 kg; S6K = 6-speed automatic / 1695 kg. Chassis plate and VIN decoding are in the manual’s General Info section.
Is this same vehicle as the BYD Yuan or Tang?
No – the S6 is a distinct model from BYD’s SUV lineup. The Yuan and Tang are separate platforms. Do not use this manual for those.
Does this cover the 2.0L and 2.4L engines?
Yes. Both BYD483QB (2.0L, 95 kW) and BYD488QA (2.4L, 118 kW) are covered with separate engine service sections.
Are the BYD-specific transmission codes covered?
Yes – 5T19 (manual), BYD6T25 (manual), and BYD6DT35 (automatic) each have dedicated chapters with ratios, service procedures, and rebuild information.
What format is the manual?
PDF (~68 MB), searchable. Instant download.
