Factory Kia Picanto Workshop Manual (2011-2017)
This is the official factory-level repair manual for the second-generation Kia Picanto TA, covering every service procedure a US or global technician needs — from routine maintenance to full powertrain overhaul — with complete wiring diagrams and torque specifications throughout.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.0L MPI Kappa (G3LA), 1.0L LPGi Kappa, 1.0L DOHC Kappa, 1.2L MPI Kappa (G4LA) |
| Diesel | N/A |
| Transmissions | 5-speed M5EF2 manual, 4-speed A4CF0 automatic |
| Drive | FWD |
| Model Years | 2011, 2012, 2013, 2014, 2015, 2016, 2017 |
| Badge Twins | Hyundai i10 (shared platform) |
Common Picanto Repairs Covered
| System | Procedures |
|---|---|
| Timing Chain (G3LA/G4LA) | Chain tensioner inspection, replacement procedure, timing mark alignment |
| Clutch & Gearbox | Clutch disc and pressure plate R&R, M5EF2 gearbox overhaul, fluid spec |
| ABS / Brake System | ABS module diagnostics, brake caliper service, pad and rotor replacement |
| HVAC & Blower Motor | Blower motor replacement, A/C compressor service, refrigerant charge specs |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the timing chain on the 1.0L Kappa engine require special tools to replace?
Yes. The G3LA Kappa timing chain service requires specific camshaft locking pins and a tensioner retaining tool to hold position during reassembly. This manual includes the complete special tooling list, part numbers, and step-by-step chain replacement procedures with torque values for every fastener.
Is the Picanto TA related to the Hyundai i10?
The second-generation Picanto (TA) shares its platform architecture with the Hyundai i10, though the two vehicles are distinct products with separate body structures and calibrations. This manual covers only the Kia Picanto TA; a separate manual is needed for the i10.
Are wiring diagrams included for the airbag and ABS systems?
Full electrical schematics are included for both the SRS airbag system and the ABS/ESC circuits, covering all model years from 2011 to 2017. Connector pinouts, wire color codes, and component locations are detailed throughout the electrical section.
What format is the manual?
The manual is delivered as a PDF file, compatible with Windows, Mac, Linux, Android, and iOS devices. After purchase, it is available for instant download and can be re-downloaded at any time without restrictions.
