Factory Kia Carens Workshop Manual (2006-2013)
This official factory-level repair manual covers the second-generation Kia Carens UN for model years 2006 through 2013, delivering the same step-by-step procedures, torque specifications, wiring diagrams, and diagnostic routines used by Kia-authorized service centers across the US and worldwide.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.0L Theta (G4KA) inline-4 |
| Diesel | 2.0L CRDi (D4EA) |
| Transmissions | 5-speed manual, 6-speed manual, 4-speed automatic |
| Drive | FWD; left- and right-hand drive variants |
| Model Years | 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013 |
| Badge Twins | Kia Rondo (North America) |
Common Carens Repairs Covered
| System | Procedures |
|---|---|
| 2.0L CRDi Timing Belt | Inspection intervals, removal, tensioner replacement, and re-timing procedures for the D4EA diesel |
| Theta Engine Oil Consumption | Piston ring inspection, valve stem seal replacement, and PCV system service for the G4KA |
| 4-Speed Automatic Transmission | Fluid and filter service, shift solenoid diagnosis, and valve body removal |
| Front Suspension & Steering | Lower control arm bushing replacement, strut service, and steering rack seal repair |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the Kia Rondo covered by this manual?
Yes. The Kia Rondo sold in the United States and Canada is a badge variant of the second-generation Carens UN platform. This manual covers the shared architecture, powertrains, and systems applicable to the Rondo for the 2007-2012 model years.
Does the manual cover the 2.0L CRDi diesel found in the UN-generation Carens?
Absolutely. The D4EA 2.0L CRDi is fully documented, including fuel injection system diagnostics, EGR service, DPF-related procedures, timing belt replacement schedules, and turbocharger inspection routines.
Are wiring diagrams included for the airbag and ABS systems?
Yes. Complete electrical schematics are included for the SRS airbag system, ABS/traction control module, engine management, HVAC, lighting circuits, and power accessories-with connector pin-out details and wire color coding throughout.
What format is the manual?
This manual is a PDF file, fully searchable and compatible with Windows, Mac, Linux, iOS, and Android devices. After purchase, you receive an instant download link and retain lifetime access for re-downloads.
