Factory Ford Escort Workshop Manual (1990-2002)
This is the official OEM dealer-level workshop software used by Ford-authorized service centers to maintain and repair fifth and sixth generation Escort models sold across the 1990-2002 model years, covering all body styles including sedan, hatchback, estate, and cabriolet variants.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.3L HCS, 1.3L Endura, 1.4L PTE, 1.6L CVH, 1.6L Zetec, 1.8L Zetec, 2.0L DOHC |
| Diesel | 1.8L Endura TC, 1.8L Endura TCI |
| Transmissions | 5-speed B5 manual, 5-speed MTX 75 manual, CTX CVT automatic |
| Drive | FWD (left and right-hand drive) |
| Model Years | 1990-2002 |
| Badge Twins | N/A |
Common Escort Repairs Covered
| System | Procedures |
|---|---|
| Zetec Timing Belt | Replacement intervals, tensioner inspection, and alignment procedures for 1.6L and 1.8L Zetec engines prone to belt-related failures |
| CTX CVT Transmission | Fluid changes, belt wear diagnosis, and control valve servicing for the known CTX reliability concerns |
| Front Suspension | Lower arm ball joint replacement, anti-roll bar link renewal, and strut top mount inspection |
| Cooling System | Thermostat housing replacement, coolant temperature sensor diagnosis, and radiator hose renewal addressing common CVH and Zetec overheating issues |
Format & Delivery
Dealer software (NOT a PDF). Compatible with Windows 11, 10, 8, 7, Vista, XP, Mac, and Linux. Instant download; lifetime re-downloads.
Frequently Asked Questions
Which Escort generations and body styles are included?
The software covers the fifth generation (MK5, 1990-1995), sixth generation (MK6, 1995-2000), and the updated MK7 (2000-2002). All body styles – three-door and five-door hatchback, four-door sedan, estate wagon, and cabriolet – are fully supported with generation-specific service procedures.
Is the CTX automatic transmission fully covered?
Yes. The CTX continuously variable transmission, which is known to develop belt wear and fluid degradation issues, receives complete coverage including fluid specifications, belt and pulley inspection procedures, and control system diagnostics alongside both the B5 and MTX 75 five-speed manual gearboxes.
Are wiring diagrams and ABS diagnostics included?
Full electrical coverage is provided, including interactive wiring diagrams for engine management, ABS circuits, airbag systems, central locking, instrument clusters, and lighting. Connector pinout data and ground point locations are included for accurate fault tracing on all Escort variants.
What format is the manual?
This product is professional OEM Ford dealer software – it is NOT a PDF. The interactive software includes searchable databases, zoom-capable diagrams, and fault-finding routines. It runs on Windows 11, 10, 8, 7, Vista, and XP, as well as Mac and Linux systems via the included virtual machine environment.
