Factory Ford Fiesta Workshop Manual (1989-1997)
This OEM dealer-grade service software covers every Ford Fiesta produced between 1989 and 1997, giving US technicians and enthusiasts the same repair data used at authorized Ford dealerships – including the performance-oriented RS1800 and XR2i variants.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.0L HCS, 1.1L HCS, 1.3L HCS / Endura-E, 1.4L CVH, 1.6L CVH, 1.8L Zetec (RS1800) |
| Diesel | 1.8L Endura-D, 1.8L Endura-D Turbo |
| Transmissions | 4-speed manual, 5-speed manual (BC and iB5 units) |
| Drive | FWD |
| Model Years | 1989-1997 |
| Badge Twins | N/A |
Common Fiesta Repairs Covered
| System | Procedures |
|---|---|
| CVH / HCS Timing Belt | Replacement intervals, tensioner inspection, alignment marks, and torque specs for all belt-driven engines |
| Head Gasket (1.4L CVH) | Known CVH head gasket failures – full R&R procedure including head resurfacing tolerances and retorque sequence |
| Clutch & iB5 Gearbox | Clutch disc, pressure plate, and release bearing replacement; gearbox rebuild specs and gear ratio data |
| Front Suspension & Subframe | Lower arm bushings, ball joints, and MacPherson strut service with alignment specifications |
Format & Delivery
Dealer software (NOT a PDF) – interactive OEM software identical to what authorized Ford service centers use, featuring searchable repair data, clickable wiring schematics, and integrated diagnostic procedures. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this manual cover the CVH head gasket issue common on 1.4L Fiestas?
Yes. The 1.4L CVH engine is well documented for head gasket failures, and this software includes the complete cylinder head removal and installation procedure, head flatness tolerances, and the full retorque sequence to prevent repeat failures.
Are the RS Turbo and RS1800 performance variants included?
Both are fully covered. The RS1800 uses the 1.8L Zetec engine and has dedicated procedures within the software, while the RS Turbo’s boost and fueling systems are addressed in the fuel and engine management sections.
Does coverage include the Endura-D turbodiesel injection system?
Yes. The 1.8L Endura-D and its turbocharged variant are covered, including indirect injection pump timing, glow plug diagnosis, and turbocharger inspection procedures.
What format is the manual?
This is professional OEM dealer software – not a PDF. It runs on Windows (XP through 11) as well as Mac and Linux, and delivers interactive wiring diagrams, searchable repair procedures, and component locators at the same level used by Ford-authorized workshops.
