Description
Factory Ford Fiesta Workshop Manual (2003-2008)
This is the official Ford dealer-level workshop software for the fifth-generation BE256 Fiesta (Mk6), covering all US and international variants built between 2003 and 2008. It delivers the same repair, diagnostic, and electrical data used by Ford-approved service centers.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.25L Duratec (SNJA/SNJB), 1.3L Duratec (BAJA), 1.4L Duratec (FXJA/FXJB), 1.6L Duratec (FYJA/FYJB), 2.0L Duratec ST150 |
| Diesel | 1.4L Duratorq TDCi (F6JA/F6JB), 1.6L Duratorq TDCi (HHJA/HHJB) |
| Transmissions | 5-speed manual IB5, 4-speed Durashift automatic |
| Drive | FWD |
| Model Years | 2003, 2004, 2005, 2006, 2007, 2008 |
| Badge Twins | N/A |
Common Fiesta Repairs Covered
| System | Procedures |
|---|---|
| Clutch & IB5 Gearbox | Clutch plate and release bearing replacement; IB5 transmission oil leak repair – a known concern on high-mileage Mk6 units |
| TDCi Fuel System | High-pressure fuel pump and injector removal/installation; bleeding procedures for 1.4L and 1.6L Duratorq engines |
| Power Steering Rack | Steering rack replacement and alignment; addresses common knocking noise reported on BE256 front-end steering components |
| ABS / ESP Module | ABS sensor replacement, module initialization, and fault code clearing via interactive diagnostic procedures |
Format & Delivery
Dealer software (NOT a PDF) – runs on Windows 11, 10, 8, 7, Vista, XP, Mac, and Linux. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this cover the Fiesta ST with the 2.0L engine?
Yes. The 2.0L Duratec ST150 engine (used in the Fiesta ST performance variant) is fully documented, including engine management calibration data, sports exhaust specifications, and uprated brake procedures specific to the ST trim.
Which body styles are included in this coverage?
All BE256 Mk6 body configurations are supported: the 3-door hatchback, 5-door hatchback, and ST variant. Both left-hand and right-hand drive configurations are covered within the software.
Are interactive wiring diagrams included for the Fiesta’s electrical systems?
Yes. The software contains full interactive wiring diagrams covering engine management, ABS/ESP, airbag circuits, central locking, lighting, instrument clusters, audio, and climate control – complete with connector pinouts, wire colors, and ground point references.
What format is the manual?
This is NOT a PDF – it is professional Ford OEM dealer software delivered as a downloadable virtual machine compatible with Windows, Mac, and Linux. It features searchable databases, clickable component locators, and the same diagnostic platform used by authorized Ford dealerships.
