Factory Ford Fiesta Workshop Manual (2017-2021)
This official Ford-sourced service manual covers every seventh-generation Fiesta sold in the US and global markets between 2017 and 2021, delivering dealer-level repair depth for owners and independent technicians alike.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.0L EcoBoost (turbocharged 3-cyl), 1.1L Duratec (Ti-VCT), 1.5L EcoBoost |
| Diesel | N/A (not covered in this manual) |
| Transmissions | 5-speed IB5 manual, 6-speed B6+ manual |
| Drive | FWD |
| Model Years | 2017, 2018, 2019, 2020, 2021 |
| Badge Twins | N/A |
Common Fiesta Repairs Covered
| System | Procedures |
|---|---|
| 1.0L EcoBoost Coolant Loss | Head gasket inspection, cylinder head removal and reseal, cooling system pressure testing and refill specifications |
| Clutch & Gearbox | Clutch plate and release bearing replacement, IB5/B6+ gearbox removal, selector fork inspection and rebuild procedures |
| Suspension | Front strut replacement, rear twist-beam bush renewal, wheel alignment specifications and torque values |
| Electrical & SYNC | CAN bus fault diagnosis, wiring diagrams with connector pinouts, SYNC infotainment module and sensor circuit troubleshooting |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the 1.0L EcoBoost in the 2017-2021 Fiesta have a known head gasket problem?
Yes. Early 1.0L EcoBoost three-cylinder engines in the Mk7 Fiesta are known for coolant loss linked to head gasket failure, sometimes appearing without obvious external leaks. This manual includes full cylinder head removal procedures, gasket torque sequences, and cooling system pressure test specifications to help diagnose and resolve the issue correctly.
Are three-door and five-door body styles both covered?
Yes. The manual applies to all seventh-generation Fiesta body configurations sold from 2017 through 2021, including three-door hatchback and five-door hatchback variants, across trim levels from base S through ST-Line and Titanium.
Does the manual include wiring diagrams and electrical troubleshooting?
Comprehensive electrical documentation is included, covering engine management, lighting circuits, power windows, central locking, and the SYNC infotainment system. Connector pinouts, wire color codes, ground locations, and CAN bus diagnostic procedures are all part of the electrical section.
What format is the manual?
The manual is a fully searchable PDF file, compatible with Windows, Mac, Linux, Android, and iOS devices. After purchase, a download link is provided immediately, and you can re-download at any time at no additional cost.
