Factory Ford F-150 Workshop Manual (2009-2014)
This is the factory-level service manual for the twelfth-generation Ford F-150 (P415), covering every trim from the base XL through the SVT Raptor. Built for US-market trucks, it delivers the same technical depth used by Ford-authorized dealership technicians.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.5L V6, 3.5L EcoBoost twin-turbo V6, 3.7L Ti-VCT V6, 4.6L 2V Triton V8, 4.6L 3V Triton V8, 5.0L Ti-VCT Coyote V8, 5.4L 3V Triton V8, 6.2L Boss V8 |
| Diesel | N/A |
| Transmissions | 6R80 6-speed automatic (RWD and 4WD) |
| Drive | RWD (2WD) and 4WD |
| Model Years | 2009, 2010, 2011, 2012, 2013, 2014 |
| Badge Twins | N/A |
Common F-150 Repairs Covered
| System | Procedures |
|---|---|
| 3.5L EcoBoost Turbocharger | Intercooler inspection, turbo boost leak diagnosis, charge-air cooler replacement, condensation purge procedures |
| 6R80 Transmission | Fluid and filter service, solenoid pack replacement, torque converter shudder diagnosis, shift quality calibration |
| Spark Plugs (5.4L Triton V8) | 2-piece spark plug extraction procedures, thread repair, anti-seize torque specifications to prevent plug ejection |
| Front Suspension / Wheel Bearings | Hub and bearing assembly replacement, ball joint inspection, alignment specifications for both 2WD and 4WD configurations |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why do the 5.4L Triton V8 spark plugs break during removal?
The 5.4L 3V Triton V8 used in early 2009-2010 F-150s is notorious for spark plug seizure due to carbon buildup around the two-piece plug design. This manual includes Ford’s approved extraction procedure, the required removal tool, thread-repair insert steps, and correct anti-seize torque specs to prevent recurrence.
Which body styles and trim levels does this manual cover?
All twelfth-generation P415 variants are included: Regular Cab, SuperCab, and SuperCrew body styles across XL, STX, XLT, FX2, FX4, Lariat, King Ranch, Platinum, Limited, SVT Raptor, and Harley-Davidson Edition trims. Bed lengths of 5.5 ft, 6.5 ft, and 8 ft are all addressed where relevant.
Are the EcoBoost-specific turbo and intercooler procedures included?
Yes. The 3.5L EcoBoost section provides dedicated coverage for both turbochargers, the charge-air intercooler, boost leak testing, condensation management, and direct-injection carbon cleaning – repairs not applicable to naturally aspirated engines and often missing from generic aftermarket guides.
What format is the manual?
The manual is a fully searchable PDF compatible with Windows, Mac, Linux, Android, and iOS devices. Download begins immediately after purchase, and you can re-download at any time at no additional charge.
