Factory Ford Ranger Workshop Manual (1998–2002)
This factory-level repair manual covers the third-generation Ford Ranger sold in the North American market from 1998 through 2002, providing dealership-grade procedures for DIY mechanics and professional technicians alike.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.3L inline-4, 3.0L Vulcan V6, 4.0L Cologne V6 OHV |
| Diesel | N/A |
| Transmissions | 5-speed manual (Mazda M5OD-R1), 5-speed automatic (5R55E) |
| Drive | 2WD and 4WD |
| Model Years | 1998, 1999, 2000, 2001, 2002 |
| Badge Twins | Mazda B-Series (B2300, B3000, B4000) — shared platform |
Common Ranger Repairs Covered
| System | Procedures |
|---|---|
| 4.0L Cologne V6 Timing Chain | Tensioner replacement, chain stretch diagnosis, timing cover reseal — a known wear issue on this engine |
| Rear ABS Speed Sensor | Sensor replacement, reluctor ring inspection, ABS fault code diagnosis |
| Front Suspension | Ball joint replacement, twin I-beam radius arm bushing service, alignment specifications |
| Cooling System | Thermostat replacement, coolant flush, water pump service, overheating diagnosis |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this manual cover the 4.0L timing chain problems the Cologne V6 is known for?
Yes. The manual includes complete timing chain and tensioner service procedures for the 4.0L Cologne V6 OHV engine, including torque specs, special tooling requirements, and front cover reseal instructions — all critical for addressing the stretch and tensioner wear this engine is prone to.
Is the Mazda B-Series pickup covered by this manual?
The Ford Ranger and Mazda B-Series (B2300, B3000, B4000) share the same platform for this generation. While this manual is specifically authored for the Ford Ranger, the mechanical content is largely applicable to the badge-twin Mazda B-Series trucks of the same era.
Are wiring diagrams for the ABS and fuel injection systems included?
Full electrical schematics are included, covering the anti-lock brake system, EEC-V fuel injection circuits, starting and charging systems, lighting, instrument cluster, and power accessories. Wire color codes, connector IDs, and ground locations are documented throughout.
What format is the manual?
This manual is delivered as a PDF file, compatible with Windows, Mac, Linux, iOS, and Android devices. The text is fully searchable, and individual pages or sections can be printed as needed. Download begins immediately after purchase.
