Factory Ford Ranger Workshop Manual (1998–2006)
This official factory-level service manual covers the first-generation Ford Ranger PE/PG/PH international pickup, giving American DIYers and professional techs the same repair data used by Ford-authorized shops worldwide.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.8L F8, 2.0L FE, 2.2L F2, 2.6L G6 |
| Diesel | 2.5L WL naturally aspirated, 2.5L WLT turbocharged |
| Transmissions | 5-speed manual M15M, 5-speed manual R15M |
| Drive | RWD and 4WD; left- and right-hand drive configurations |
| Model Years | 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006 |
| Badge Twins | Mazda B-Series (B2500, B2600) — shared platform |
Common Ranger Repairs Covered
| System | Procedures |
|---|---|
| WLT Turbo — Intercooler & Boost Leaks | Turbocharger removal, intercooler hose inspection, boost pressure diagnostics and torque specs |
| Front Axle & 4WD Hub Engagement | Manual locking hub overhaul, front differential service, CV joint replacement procedures |
| Cooling System — WL/WLT Overheating | Thermostat replacement, radiator flush, water pump R&R with factory torque values |
| Rear Leaf Spring & Shock Absorbers | Leaf spring pack disassembly, U-bolt torque specs, shock absorber mounting replacement |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the WLT turbo diesel fully covered, including injection timing?
Yes. The 2.5L WLT turbocharged diesel section includes injection pump timing procedures, fuel system bleeding, injector removal and testing, and complete turbocharger service specifications with all required torque values.
Does this manual cover the Mazda B-Series badge twin?
The Ford Ranger PE/PG/PH shares its platform with the Mazda B2500 and B2600. While this manual is produced for the Ford Ranger, the mechanical procedures for shared components — including the WL/WLT engines and M15M/R15M gearboxes — are directly applicable to equivalent Mazda B-Series variants.
Are wiring diagrams included for the electrical and lighting systems?
Yes. Complete electrical schematics cover the charging circuit, starter system, exterior and interior lighting, instrument cluster, and engine management wiring. Connector pinouts and wire color codes are included throughout to support efficient fault diagnosis.
What format is the manual?
The manual is a PDF file delivered via instant download after purchase. It is fully searchable and compatible with Windows, Mac, Linux, Android, and iOS devices. Individual pages or entire sections can be printed for workshop use.
