Factory Isuzu Pickup Workshop Manual (1988–2002)
This official factory-level repair manual covers the complete TF-series Isuzu Pickup sold in the US and worldwide from 1988 through 2002, delivering dealer-grade procedures for every major system on both 2WD and 4WD variants.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.0L 4ZC1, 2.2L C22NE / 22LE / 20LE, 2.2L Di/SE, 2.3L 4ZD1, 2.6L 4ZE1, 3.2L 6VD1 V6 |
| Diesel | 2.5L 4JA1, 2.8L 4JB1-T (turbocharged) |
| Transmissions | 5-speed manual, 4-speed automatic |
| Drive | RWD and 4WD (part-time); left- and right-hand drive |
| Model Years | 1988–2002 |
| Badge Twins | Isuzu KB, Isuzu Faster, Holden Rodeo (TFR/TFS chassis) |
Common Pickup Repairs Covered
| System | Procedures |
|---|---|
| 4ZE1 Timing Belt | Belt replacement, tensioner inspection, and camshaft seal renewal — a known high-interval wear item on the 2.6L |
| 4JB1-T Turbocharger | Boost pressure diagnosis, wastegate actuator adjustment, and turbo oil-feed line inspection |
| Front Leaf Spring / Suspension | Leaf spring bushing replacement, U-bolt torque, and front shock absorber swap for TF-series solid-axle front end |
| Brake System | Rear drum brake adjustment, master cylinder rebuild, and proportioning valve bleeding — rear brake fade is a common complaint on heavier payloads |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does my 2.6L 4ZE1 overheat at highway speeds?
The 4ZE1 is known for degrading coolant hoses and a thermostat housing that cracks with age. The manual covers complete cooling system diagnostics, thermostat replacement torque specs, and radiator flush procedures to help resolve overheating on 1988–2002 Isuzu Pickups equipped with this engine.
Is this manual the same as the Holden Rodeo or Isuzu KB service guide?
Yes — the Isuzu Pickup TF platform was sold concurrently as the Isuzu KB, Isuzu Faster, and Holden Rodeo (TFR/TFS chassis codes). The procedures, torque figures, and wiring diagrams in this manual apply directly to all of those badge variants for the 1988–2002 production run.
Does the manual cover 4WD transfer case service?
Full coverage is included for the part-time 4WD system fitted to TF-series models, including transfer case disassembly, shift fork inspection, output shaft seal replacement, and front axle hub engagement procedures with complete torque specifications.
What format is the manual?
The manual is a PDF file delivered via instant download immediately after purchase. It is fully searchable and compatible with Windows, Mac, Linux, iOS, and Android devices. Individual pages or entire sections can be printed for shop use, and zoom functionality keeps all wiring diagrams and illustrations sharp at any magnification.
