Factory Jeep Grand Cherokee Workshop Manual (2005-2010)
This is the official factory-level service manual for the third-generation Jeep Grand Cherokee WK, giving American owners and technicians complete repair and maintenance data for every 2005-2010 model year variant.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.7L MPI V6, 4.7L MPI V8, 5.7L HEMI V8, 6.1L HEMI V8 (SRT8) |
| Diesel | 3.0L V6 Turbo |
| Transmissions | 5-speed 545RFE automatic, 5-speed NAG1 (W5A580) automatic |
| Drive | 4×2 (RWD), 4×4 (4WD) |
| Model Years | 2005, 2006, 2007, 2008, 2009, 2010 |
| Badge Twins | N/A |
Common Grand Cherokee Repairs Covered
| System | Procedures |
|---|---|
| Transfer Case (NV245/NV244) | Fluid service, actuator replacement, and mode switch diagnosis for common 4WD engagement faults |
| 5.7L HEMI MDS | Multi-Displacement System lifter replacement, valley cover removal, and associated tick diagnosis |
| EVIC / Electrical | Wiring diagrams, PCM pinouts, and CAN bus diagnostics covering ABS, airbag, and climate control circuits |
| Suspension & Steering | Front control arm bushing replacement, track bar adjustment, and rear air suspension leak repair |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the manual cover the SRT8 with the 6.1L HEMI?
Yes. In addition to the 3.7L V6 and 5.7L HEMI V8 variants, this manual includes procedures and specifications for the high-output 6.1L HEMI V8 fitted to the Grand Cherokee SRT8, covering all trim levels from Laredo through Overland and SRT8 for the 2005-2010 WK generation.
Which platform does the WK Grand Cherokee share?
The third-generation Grand Cherokee (chassis code WK) rides on a unibody platform developed exclusively by Jeep for this generation. It is not a badge twin of another Chrysler product sold in the US during this period, though it shares some drivetrain components with the Commander (XK) built on the same assembly line in Jefferson North.
Are transfer case and 4WD procedures included?
Full coverage is provided for both the NV245 and NV244 transfer cases used across 4×4 Grand Cherokee variants. This includes fluid specifications, actuator and encoder motor replacement, and step-by-step diagnostic procedures for common 4WD engagement and mode-switching faults.
What format is the manual?
The manual is delivered as a fully searchable PDF, compatible with Windows, Mac, iOS, and Android devices. After purchase, you can download it immediately and re-download at any time for the life of your account.
