Description
Factory Lexus IS 250 Workshop Manual (2006-2013)
This factory-level repair manual covers every second-generation Lexus IS 250 sold in the US and worldwide from model year 2006 through 2013, delivering OEM-grade service procedures, wiring diagrams, and torque specifications in a single downloadable resource.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.5L 4GR-FSE V6 (direct injection) |
| Diesel | 2.2L 2AD-FHV (IS 220d) |
| Transmissions | 6-speed RA62 manual, 6-speed RA63 manual, 6-speed A960E automatic |
| Drive | RWD; AWD (IS 250 AWD) |
| Model Years | 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013 |
| Badge Twins | Toyota Altezza RS (export markets); IS 220d (diesel variant) |
Common IS 250 Repairs Covered
| System | Procedures |
|---|---|
| 4GR-FSE Carbon Buildup | Intake valve and port cleaning procedures for direct-injection carbon accumulation |
| A960E Transmission | Fluid service, solenoid replacement, and shift-quality diagnostic routines |
| Brake System | Rear caliper service, brake pad replacement, ABS module diagnostics |
| Cooling System | Thermostat replacement, coolant flush, water pump inspection and R&R |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does the IS 250 suffer carbon buildup, and does this manual cover the fix?
The 4GR-FSE uses direct injection, which means fuel never washes the intake valves – leading to carbon deposits over time. The manual includes full intake manifold removal procedures and valve cleaning specifications to address this well-documented issue.
Is the IS 250 AWD variant covered alongside the standard RWD model?
Yes. The manual addresses both the rear-wheel-drive IS 250 and the all-wheel-drive IS 250 AWD sold from 2006-2013, including front differential, transfer case, and AWD driveshaft procedures unique to the AWD platform.
Are A960E automatic transmission overhaul procedures included?
Complete A960E coverage is included: valve body disassembly, clutch pack clearances, solenoid testing, fluid capacity specifications, and shift-pattern reprogramming notes are all detailed within the transmission chapter.
What format is the manual?
The manual is delivered as a PDF file, compatible with any device running a standard PDF reader. You can search by keyword, zoom into diagrams, and print individual pages as needed.
