Description
Factory Lexus RX350 Workshop Manual (2007–2009)
This is the factory-level service manual for the second-generation Lexus RX350 luxury crossover — the go-to reference for technicians and serious DIYers working on the 2007, 2008, or 2009 model year in the US market. Wiring diagrams, torque specs, and step-by-step procedures are all included.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.5L 2GR-FE V6 (270 hp / 251 lb-ft) |
| Diesel | N/A |
| Transmissions | 5-speed automatic (U151E/U151F) |
| Drive | FWD (GSU30) / AWD (GSU35) |
| Model Years | 2007, 2008, 2009 |
| Badge Twins | Toyota Harrier (Japan market) |
Common RX350 Repairs Covered
| System | Procedures |
|---|---|
| 2GR-FE Timing Chain | Tensioner inspection, chain guide replacement, timing cover reseal — a known wear item on high-mileage 2GR-FE engines |
| Transmission | ATF fluid change intervals, solenoid diagnostics, shift quality correction procedures |
| Brake & VSC System | Brake actuator bleeding, ABS/VSC sensor replacement, caliper overhaul |
| HVAC / Climate Control | Blend door actuator replacement, refrigerant recharge specs, blower motor service |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
My 2GR-FE is making a rattling noise on cold start — does the manual cover timing chain service?
Yes. Cold-start timing chain rattle is a documented concern on the 2GR-FE V6. The manual includes full timing chain tensioner inspection procedures, chain guide replacement steps, front cover removal/installation torque sequences, and sealing specifications to resolve this issue properly.
Does this manual cover both the FWD and AWD versions of the RX350?
It covers both drivetrain configurations — the GSU30 chassis (front-wheel drive) and the GSU35 chassis (all-wheel drive). AWD-specific content includes the rear differential, propeller shaft service, and transfer case procedures unique to the four-wheel-drive variant.
Are complete wiring diagrams included for the navigation and smart key systems?
Yes. The electrical section provides full circuit diagrams covering the engine management system, ABS/VSC stability control, smart key/push-button start, navigation and audio, power windows, door locks, and all sensor circuits with connector pinout locations and ground points.
What format is the manual?
The manual is delivered as a PDF file. After purchase you receive an instant download link. The file is fully searchable, compatible with Windows, Mac, iOS, and Android devices, and can be printed by section as needed. Your download link remains active for lifetime re-access.
