Factory Mercedes CLA200 Workshop Manual (2013–2018)
This is the factory-level service manual for the Mercedes-Benz CLA200 (C117 coupe and X117 Shooting Brake), covering every production year from 2013 through the 2018 facelift — the same technical resource used by authorized Mercedes-Benz dealerships across the US.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | M270 1.6L turbocharged inline-4 (156 hp, direct injection) |
| Diesel | N/A |
| Transmissions | 7G-DCT 7-speed dual-clutch automatic, 6-speed manual |
| Drive | FWD; 4MATIC AWD (select variants) |
| Model Years | 2013–2018 (pre-facelift 2013–2016; facelift 2016–2018) |
| Badge Twins | Mercedes-Benz A-Class (W176), B-Class (W246) — shared MFA platform |
Common CLA200 Repairs Covered
| System | Procedures |
|---|---|
| M270 Timing Chain | Timing chain tensioner inspection, chain replacement, and camshaft timing verification — a known wear item on early M270 engines |
| 7G-DCT Dual-Clutch Transmission | Mechatronic unit diagnostics, fluid service, clutch pack replacement, and shudder/hesitation fault-finding |
| Engine Cooling System | Thermostat replacement, coolant flush, water pump service, and coolant leak diagnosis |
| Suspension & Steering | Front control arm bushing replacement, wheel alignment specifications, and electric power steering calibration |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the M270 timing chain a common problem on the CLA200?
Yes. The M270 1.6L engine used in the 2013–2018 CLA200 has a documented history of timing chain tensioner wear, particularly on pre-facelift models. This manual covers the full timing chain inspection and replacement procedure, including torque specs and special tool requirements, so you can address the issue before it causes internal engine damage.
Does this manual cover both the C117 coupe and the X117 Shooting Brake?
Yes. Both the C117 four-door coupe sold in the US and the X117 Shooting Brake estate variant share the same powertrain and chassis architecture. The manual covers mechanical, electrical, and body procedures applicable to both body styles across the full 2013–2018 production run, including pre-facelift and post-facelift specifications.
Are wiring diagrams and CAN-bus diagnostics included?
Yes. The electrical section provides full circuit diagrams for the engine management system, COMAND infotainment, climate control, lighting, and central locking. CAN-bus network topology, connector pinouts, wire color codes, fuse and relay locations, and sensor testing values are all documented to support accurate electrical fault diagnosis.
What format is the manual?
This manual is delivered as a searchable PDF file. After purchase you receive immediate download access — no shipping required. The file is compatible with Windows and macOS computers, tablets, and smartphones, and individual pages can be printed for use in the shop. Your download link is available for life, so you can retrieve the file whenever needed.
