Factory Mercedes CLK230 Kompressor Workshop Manual (1997–2003)
This official factory-level service manual covers the W208-chassis Mercedes CLK230 Kompressor sold in North American and global markets from 1997 through 2003, giving technicians and DIY owners dealer-grade repair authority for both the Coupe and Cabriolet body styles.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | M111 2.3L supercharged inline-4 (Eaton Kompressor), ~193 hp |
| Diesel | N/A |
| Transmissions | 5-speed automatic (722.6), 5-speed manual gearbox |
| Drive | RWD |
| Model Years | 1997–2003 |
| Badge Twins | N/A |
Common CLK230 Kompressor Repairs Covered
| System | Procedures |
|---|---|
| Eaton Supercharger (M111) | Supercharger belt replacement, bypass valve inspection, oil service intervals, boost pressure diagnosis |
| 722.6 Automatic Transmission | Conductor plate replacement, fluid and filter service, shift solenoid diagnosis |
| Convertible Roof Hydraulics | Hydraulic pump seal replacement, roof latch adjustment, cylinder leak-down testing (Cabriolet) |
| ABS / Brake System | ABS wheel speed sensor replacement, brake pad and rotor service, brake fluid flush procedures |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does my CLK230 Kompressor lose boost pressure, and does the manual cover supercharger repair?
Yes. The M111 Eaton supercharger is prone to bypass valve wear and drive belt slippage over time, both of which reduce boost output. The manual includes complete supercharger service procedures — bypass valve removal, belt tension specifications, and oil fill intervals — so you can restore full performance without dealer labor rates.
Does this manual cover both the W208 Coupe and Cabriolet?
Yes. Both body styles built on the W208 platform between 1997 and 2003 are fully covered, including Cabriolet-specific sections on the hydraulic convertible roof system, soft-top latch alignment, and wind deflector removal.
Are wiring diagrams included for the CLK230’s electrical systems?
Yes. The manual contains full circuit diagrams covering the engine management system, ABS, climate control, central locking, power windows, lighting, and multiplexed CAN bus architecture, along with connector pinouts and ground-point locations.
What format is the manual?
The manual is a PDF file, compatible with any PDF reader on Windows, macOS, iOS, or Android. You can search by keyword, zoom into diagrams, and print individual pages for bench use. Download is instant following purchase, with unlimited future re-downloads included.
