Description
Factory Volkswagen Amarok Workshop Manual (2010-2016)
This OEM-level service manual covers every first-generation Amarok pickup sold in US-friendly markets and worldwide, delivering the same repair depth used by VW-authorized dealerships – from routine maintenance to full drivetrain rebuilds.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.0L TSI (CFPA) |
| Diesel | 2.0L TDI CR 03L – CDCA (90 kW), CDBA (103 kW), CNEA (120 kW), BiTDI CDCA (132 kW) |
| Transmissions | 6-speed manual, 8-speed automatic |
| Drive | RWD (4×2) and 4MOTION permanent AWD |
| Model Years | 2010, 2011, 2012, 2013, 2014, 2015, 2016 |
| Badge Twins | N/A |
Common Amarok Repairs Covered
| System | Procedures |
|---|---|
| TDI Timing Belt & Tensioner | Complete replacement procedure with torque specs for 2.0L TDI engines prone to premature wear |
| EGR System | EGR valve cleaning, cooler inspection, and replacement steps addressing common TDI sooting issues |
| 8-Speed Automatic Transmission (ZF 8HP) | Fluid service, mechatronic unit diagnostics, and selector shaft seal replacement |
| Front Suspension & CV Joints | Control arm bushing replacement, wheel bearing press procedure, and CV boot/joint service |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Which body styles and chassis codes are included in this manual?
The manual covers all first-generation Amarok body configurations built under chassis codes 2H and S1B, including both the single cab and double cab layouts. Trim levels from base Startline through Highline and Ultimate editions are all addressed within the same documentation.
Are all TDI output variants documented, including the BiTurbo?
Yes. The manual covers the full 2.0L TDI range – CDCA at 90 kW, CDBA at 103 kW, CNEA at 120 kW, and the BiTDI CDCA producing 132 kW – with output-specific torque values and injection system procedures where applicable.
Does this manual include wiring diagrams and electrical diagnostics?
Complete electrical coverage is included: engine management wiring, ABS/ESP module diagrams, airbag system schematics, central locking, instrument cluster, lighting circuits, connector pinouts, and ground point locations. Diagnostic flowcharts for common fault codes are also provided.
What format is the manual?
The manual is delivered as a fully searchable PDF file. It is compatible with Windows, Mac, Linux, Android, and iOS devices. Individual pages or entire sections can be printed for workshop bench use, and the search function allows instant look-up of part numbers, torque figures, or specific procedures.
