Factory Ford Courier Workshop Manual (1998–2006)
This official factory-level repair manual covers every fourth-generation Ford Courier PE/PG/PH built between 1998 and 2006, giving US and global technicians the complete technical reference needed for professional-grade diagnostics, maintenance, and overhaul work.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 1.8L F8, 2.0L FE, 2.2L F2, 2.6L G6 |
| Diesel | 2.5L WL, 2.5L WLT (turbocharged) |
| Transmissions | 5-speed manual (M15M, R15M) |
| Drive | RWD / 4WD; left- and right-hand drive |
| Model Years | 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006 |
| Badge Twins | Mazda Bravo (B-Series), Ford Ranger (some markets) |
Common Courier Repairs Covered
| System | Procedures |
|---|---|
| 2.5L WLT Turbo Diesel | Turbocharger inspection and replacement; injection pump timing; glow plug circuit diagnosis — a well-known hard-start issue on higher-mileage units |
| Front Leaf Spring Suspension | Leaf spring pack removal, bushing replacement, and re-torque to factory specs; correction for common front-end wander complaint |
| Clutch & Gearbox | Clutch disc and pressure plate R&R, hydraulic clutch line bleeding, M15M/R15M gearbox rebuild and seal replacement |
| Electrical System | Full wiring diagrams with connector pin-outs; charging system fault diagnosis; alternator and starter replacement procedures |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Why does my 2.5L WLT turbo diesel hard-start in cold weather — is this covered?
Yes. The manual includes complete glow plug system diagnostics, injection timing procedures, and turbocharger inspection steps specifically for the WLT engine. Cold-start hard-start complaints on the WLT are frequently traced to worn glow plugs or incorrect injection pump timing, both of which are addressed with step-by-step factory procedures.
Is the Ford Courier the same truck as the Mazda Bravo or Ford Ranger?
The fourth-generation Ford Courier PE/PG/PH shares its platform and most mechanical components with the Mazda Bravo (B-Series). In certain markets it was also sold as a variant of the Ford Ranger. This manual covers the Ford Courier–specific configurations, including all chassis codes (PE, PG, PH) and both left- and right-hand-drive builds.
Does the manual include wiring diagrams and electrical schematics?
Absolutely. The electrical section contains full circuit diagrams covering engine management, lighting, instrument cluster, HVAC controls, central locking, and the charging and starting systems. Each diagram identifies wire colors, connector locations, pin assignments, and ground points to speed up fault diagnosis.
What format is the manual?
The manual is a PDF file, downloadable immediately after purchase. It is fully searchable, zoomable, and compatible with any device — PC, Mac, tablet, or smartphone. Individual pages or entire sections can be printed as needed for use in the shop.
