Factory Mitsubishi Galant Workshop Manual (2004–2012)
This factory-level repair manual covers every ninth-generation Mitsubishi Galant sold in North America from 2004 through 2012, giving independent shops and DIY owners the same technical depth as a Mitsubishi dealership service department.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.4L 4G69 MIVEC inline-4, 3.8L 6G75 MIVEC V6 |
| Diesel | N/A |
| Transmissions | 4-speed automatic, 5-speed automatic (Sportronic) |
| Drive | FWD |
| Model Years | 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012 |
| Badge Twins | N/A |
Common Galant Repairs Covered
| System | Procedures |
|---|---|
| Timing Belt (4G69 / 6G75) | Inspection, removal, installation, tensioner replacement, and interval specifications |
| MIVEC Variable Valve Timing | Oil control valve cleaning, actuator testing, and P0075/P0085 fault diagnosis |
| Automatic Transmission | Fluid and filter service, solenoid replacement, shift quality diagnosis |
| Front Struts & Control Arms | Strut assembly replacement, lower control arm bushing service, wheel alignment specs |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does the 4G69 engine have a timing belt or timing chain?
The 2.4L 4G69 MIVEC uses a timing belt, not a chain. Mitsubishi recommends inspection at 60,000 miles and replacement by 100,000 miles. The manual includes full belt routing diagrams, tensioner torque values, and camshaft alignment marks for both the 4G69 and the 3.8L 6G75 V6.
Which trim levels and chassis codes are covered?
The manual covers all DJ-series ninth-generation Galant trims sold in North America: DE, ES, LS, GTS, and the Ralliart sport variant. All trim-specific wiring, emissions calibrations, and suspension tuning differences are addressed within the relevant sections.
Are complete wiring diagrams included for the ABS and airbag systems?
Yes. The electrical section contains full circuit schematics for ABS, SRS airbags, engine management, climate control, power windows, and lighting. Each diagram identifies connector pinouts, wire colors, and physical component locations to support accurate OBD-II fault diagnosis.
What format is the manual?
The manual is delivered as a PDF file. It is fully searchable by keyword, compatible with Windows, Mac, iOS, and Android devices, and individual pages can be printed for bench-side reference. Download is immediate after purchase, with unlimited re-downloads available at no extra cost.
