Factory Mitsubishi Pajero Workshop Manual (2003-2006)
This official factory-level service manual covers the third-generation Mitsubishi Pajero V77W facelift in the US and global markets – the same reference material Mitsubishi-authorized dealerships rely on for diagnostics, repair, and maintenance.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 3.8L 6G75 V6 |
| Diesel | N/A |
| Transmissions | 5-speed V5A51 automatic |
| Drive | Super Select 4WD (2H / 4H / 4HLc / 4LLc) |
| Model Years | 2003, 2004, 2005, 2006 |
| Badge Twins | Mitsubishi Montero (North America), Mitsubishi Shogun (UK) |
Common Pajero Repairs Covered
| System | Procedures |
|---|---|
| V5A51 Automatic Transmission | Fluid service, valve body overhaul, shift solenoid replacement, INVECS-II adaptation reset |
| Super Select 4WD Transfer Case | Actuator diagnosis, mode switch replacement, transfer case fluid change, encoder motor service |
| 6G75 Engine – Timing Chain | Timing chain tensioner inspection and replacement, known rattle diagnosis on cold start, front cover reseal |
| Suspension & Steering | Front upper/lower control arm bushing replacement, rear trailing arm service, power steering pump overhaul and fluid flush |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the 6G75 timing chain tensioner procedure included?
Yes. The 6G75 V6 is known for timing chain rattle on cold starts due to tensioner wear. The manual includes the complete tensioner inspection, removal, and replacement procedure along with torque specifications and front cover reseal instructions.
Does this cover the Montero and Shogun badge twins?
Yes. The V77W platform underpins the Mitsubishi Montero sold in North America and the Mitsubishi Shogun sold in the UK for the same 2003-2006 period. All three share the same mechanical and electrical architecture covered by this manual.
Are Super Select 4WD and transfer case procedures included?
Absolutely. The manual covers the full Super Select 4WD system including transfer case disassembly, encoder motor replacement, mode actuator diagnostics, and differential lock service – all with step-by-step instructions and wiring diagrams.
What format is the manual?
This manual is delivered as a PDF document. It is fully searchable, compatible with Windows, Mac, iOS, and Android devices, and you can print any pages you need for the shop floor. Once purchased, you can re-download it anytime at no additional cost.
