Factory Toyota 4Runner Workshop Manual (2003–2009)
This factory-level repair manual covers the fourth-generation N210 Toyota 4Runner sold across the United States, giving DIY owners and professional technicians everything needed to service, diagnose, and rebuild these capable SUVs at home or in the shop.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Gasoline | 4.0L 1GR-FE V6, 4.7L 2UZ-FE V8 |
| Diesel | N/A (US market) |
| Transmissions | 5-speed automatic A750E / A750F |
| Drive | 2WD and 4WD (part-time and full-time with center differential lock) |
| Model Years | 2003, 2004, 2005, 2006, 2007, 2008, 2009 |
| Badge Twins | N/A |
Common 4Runner Repairs Covered
| System | Procedures |
|---|---|
| 1GR-FE Valve Cover & Gaskets | Oil leak diagnosis, valve cover removal, gasket replacement, torque specs |
| A750E/A750F Transmission | Fluid and filter service, solenoid replacement, torque converter removal, full rebuild procedures |
| KDSS (Kinetic Dynamic Suspension) | Hydraulic cylinder inspection, bleeding procedure, stabilizer bar disconnection and replacement |
| Front & Rear Differential | Fluid service, pinion seal replacement, diff rebuild specifications and torque values |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Is the 1GR-FE V6 timing chain procedure included?
Yes. The manual contains complete timing chain inspection, tensioner service, and replacement procedures for the 4.0L 1GR-FE V6, including all torque specifications and reassembly sequences required to return the engine to factory spec.
Does coverage differ between the SR5, Sport, and Limited trim levels?
All three N210 trim levels share the same core mechanical architecture, and this manual covers each of them. Trim-specific systems such as the Limited’s KDSS hydraulic suspension, Multi-Terrain Select, and factory navigation/audio wiring are also documented.
Are complete wiring diagrams included for the 4WD control system?
Yes. Full electrical schematics are provided for the 4WD control module, transfer case actuator, multi-terrain select switch, ABS, airbag system, and all other electronic control units — including connector pinouts, wire colors, and ground point locations.
What format is the manual?
The manual is delivered as a PDF file, compatible with Windows, macOS, Linux, tablets, and smartphones. No software installation is required — any standard PDF reader will open it. You can search by keyword, zoom into diagrams, and print individual pages as needed.
