Factory Toyota RAV4 Workshop Manual (2013-2018)
This factory-level repair manual covers the fourth-generation XA40 RAV4 sold across the United States from 2013 through 2018, giving DIYers and professional technicians identical procedures to those used by Toyota dealership service departments.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 2.5L 2AR-FE four-cylinder (176 hp) |
| Petrol Hybrid | 2.5L 2AR-FXE Atkinson-cycle (RAV4 Hybrid) |
| Transmissions | 6-speed U760E/F automatic |
| Drive | FWD (2WD) and AWD |
| Model Years | 2013, 2014, 2015, 2016, 2017, 2018 |
| Badge Twins | N/A |
Common RAV4 Repairs Covered
| System | Procedures |
|---|---|
| 2AR-FE Oil Consumption | Piston ring inspection, replacement, and cylinder bore measurement per TSB EG-0055T |
| AWD Rear Differential | Rear coupling actuator removal, fluid service, and vibration diagnosis |
| Brake System | Front and rear caliper overhaul, rotor resurfacing specs, ABS actuator bleeding procedure |
| HVAC | Blend door actuator replacement, refrigerant charge specs (R-134a), evaporator cleaning |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Does this manual address the known 2AR-FE excessive oil consumption issue?
Yes. The manual includes full engine mechanical procedures for the 2.5L 2AR-FE, covering piston ring inspection, oil control ring clearance measurements, and cylinder bore evaluation – the steps required to properly diagnose and remedy the oil consumption concern documented in Toyota TSB EG-0055T for 2013-2018 RAV4 models.
Which XA40 trim levels and configurations are included?
All US-market fourth-generation XA40 variants are covered: LE, XLE, SE, Limited, and Platinum trims, in both FWD (2WD) and AWD configurations. The RAV4 Hybrid (2016-2018) with its 2AR-FXE engine and high-voltage system is also fully covered.
Are hybrid high-voltage and electrical wiring diagrams included?
Yes. The manual provides complete circuit diagrams for all model years, including the hybrid high-voltage system, engine management, ABS and traction control, supplemental restraint system, power accessories, and infotainment. Color-coded schematics include connector locations and ground points.
What format is the manual?
The manual is delivered as a PDF file compatible with Windows, Mac, Linux, iOS, and Android devices. Full-text search, zoom-capable illustrations, and printable pages make it practical for both shop and garage use.
