Factory Toyota Tundra Workshop Manual (2007–2021)
This is the same factory-level service manual Toyota dealerships used to maintain and repair the second-generation XK50 Tundra sold across the US market from 2007 through 2021, covering every cab style, trim grade, and powertrain combination offered during that run.
Powertrain & Drive Coverage
| Component | Variants Covered |
|---|---|
| Petrol | 4.0L 1GR-FE V6, 4.7L 2UZ-FE V8, 4.6L 1UR-FE V8, 5.7L 3UR-FE V8 |
| Diesel | N/A |
| Transmissions | 5-speed A750E/F automatic, 6-speed AB60E/F automatic, 6-speed A760E/F automatic |
| Drive | RWD, 4WD |
| Model Years | 2007–2021 |
| Badge Twins | N/A |
Common Tundra Repairs Covered
| System | Procedures |
|---|---|
| Rear Differential | Rear diff pinion seal replacement — a known leak point on high-mileage XK50 trucks |
| Exhaust Manifold | Cracked manifold and stud extraction on 5.7L 3UR-FE V8 — widespread issue across model years |
| Brake System | Rear brake caliper service and parking brake adjustment; rotor and pad replacement with torque specs |
| Secondary Air Injection | Air injection pump diagnosis and replacement — common P0410/P0418 fault on V8 models |
Format & Delivery
PDF. Instant download; lifetime re-downloads.
Frequently Asked Questions
Are cracked exhaust manifolds addressed in this manual?
Yes. Cracked exhaust manifolds and broken studs are a well-documented issue on the 5.7L 3UR-FE V8. The manual provides full exhaust manifold removal procedures, stud extraction guidance, and torque specifications for reassembly on all V8 variants.
Which cab and trim configurations are included?
All XK50-platform body styles are covered — Regular Cab, Double Cab, and CrewMax — across every US trim grade including SR, SR5, Limited, Platinum, 1794 Edition, and TRD Pro for the full 2007–2021 model range.
Does the manual cover the 4WD transfer case and front differential?
Yes. Four-wheel-drive system service is fully documented, including transfer case fluid service, front differential overhaul, front axle hub assembly, and actuator diagnostics for both part-time and Active Traction Control-equipped models.
What format is the manual?
The manual is a PDF file, downloadable immediately after purchase. It is fully searchable and compatible with Windows, Mac, Linux, iOS, and Android devices, including tablets and smartphones.
